PLUMBING
Replacement Parts & Accessories for
CHG Encore ® Pre-Rinses
©2012 Franklin Machine Products
1
2
SPOUT ADAPTORS
INLET NIPPLE KIT
No. 117-1334
• For installing faucets in a standard
2" backsplash
• Converts female inlets to male
• Kit includes: two 1 ⁄ 2 " NPS x 1 1 ⁄ 2 " brass nipples
with lock nuts and washers, and two
1
⁄ 2 " NPT x 1 ⁄ 2 " sweat brass elbows
• CHG nos. KL40-1000, KN40-1000
SWIVEL JOINT
No. 106-1210
• For swivel arm pre-rinses
• 2 1 ⁄ 2 " L x 1 1 ⁄ 2 " W
• CHG nos. KL50Y051, KN50Y05
1. No. 106-1217 For riser pipe
• 3 ⁄ 8 " NPT female to spout thread
• Spout can be added to the top of riser pipe
• CHG nos. KL50X076, KN50X076
2. No. 106-1216 For faucet base
• 3 ⁄ 8 " NPT male to spout thread
• Spout can be added to pre-rinse faucet base
• CHG nos. KL50X075, KN50X075
Hose Adaptor
No. 106-1203
• Adapts CHG or T&S hose
to Fisher spring body on top
of the riser tube
• Chrome-plated brass
• CHG nos. KL50X127, KN50X127
NIPPLE KIT
No. 117-1336
• For simple installation of deck mount
faucets and pre-rinses
• Converts female inlet to male inlet
• Kit includes 2 of each: ½" NPS x 2" L
nipples, washers, and lock nuts
• CHG no. KL60Y010
WATTS ® BACKFLOW
PREVENTER
No. 117-1409
• For use on bottom of pre-rinse
riser tubes
• 3 ⁄ 8 " NPT male inlet
• 3 ⁄ 8 " NPT female outlet
• Rated 125 PSI
• Chrome-plated brass
• CHG no. K50X139B
SWING TO RIGID
SPOUT ADAPTOR
No. 106-1202
• Converts a standard Encore ®
swivel spout to a 3 ⁄ 8 " NPT riser
pipe or rigid gooseneck spout
• Chrome-plated brass
• CHG nos. KL50X122,
KN50X122
DECK MOUNT KIT
NIPPLE
No. 106-1254
• For model K53-5024-12W
• 3 ⁄ 8 " NPT x 5 ⁄ 8 " ID hose
• Stainless steel
• CHG no. KL55X002
Phone: [phone]
No. 117-1408
• For simple installation of
deck faucets and pre-rinses
• Converts female inlets to
male
• Kit includes 2 each:
1
⁄ 2 " NPS x 2" long nipples,
washers, lock nuts
• CHG no. KN60Y010
24-Hour Fax: [phone]
ADJUSTABLE SUPPLY INLET
Permits easy, fast installation by providing
adjustability of different faucet or pre-rinse
centers to match varying installation centers.
No. 106-1206
• 2" total range
• 1 ⁄ 2 " NPT female inlets
• Chrome-plated brass
• CHG no. KN60Y005
