PLUMBING
Wall mount pre-rinses
by CHG ®
Encore ® Pre-Rinse
No. 107-1120
• 1 ⁄ 2 " NPT female inlets on 8" centers
• 34" high with 15" overhang
• Contains internal check valves
• Conforms to the Energy Policy
Act of 2005 when using the included
water-saving spray face
• Chrome-plated brass
• CHG nos. KL53-1000, KN53-1000
No. 106-1194 Replacement spray valve
• CHG nos. K50Y002, KL50Y002,
KN50Y002
ENCORE ® SWIVEL ARM
PRE-RINSE
No. 107-1128
• Swivel arm allows a 360° rotation
• 1 ⁄ 2 " NPT male inlets on 8" centers
• 34" high with 12" overhang
• Contains internal check valves
• Includes water-saving and conventional
spray heads, wall bracket, and heavy-duty
swivel arm bracket
• Conforms to the Energy Policy
Act of 2005 when using the included
water-saving spray face
• Chrome-plated brass
• CHG nos. K53-5526-12, KL53-5526-12
SWIVEL ARM PRE-RINSE
No. 107-1142
• Swivel arm (No. 106-1249) allows 360° rotation
• ½" NPT male inlets on 8" centers
• 24" high with 12" overhang
• Contains internal check valves
• Includes spray valve (No. 106-1194), spout
(No. 110-1177), wall bracket, add-on faucet
fitting, 20" hose with set screw, mounting
hardware, and instructions
• Conforms to the Energy Policy Act of 2005
• Chrome-plated brass
• CHG no. K53-5024-12W
No. 106-1194 Replacement spray valve
• CHG nos. K50Y002, KL50Y002, KN50Y002
No. 106-1194 Replacement spray valve
• CHG nos. K50Y002, KL50Y002, KN50Y002
