Penetrating Item ( s ) F-Rating T-Rating L-Rating W-Rating Product
METALLIC PENETRANTS IN CONCRETE FLOORS / WALLS ( CONTINUED )
Max . 1 ” steel , copper , cast iron steel conduit , or |
|
|
EMT ( Max . Qty 5 ) |
3 Hr |
◼ |
Max . 2 ” and 3 ” Steel conduit or EMT
Max . 30 ” steel , cast iron , 6 ” copper , conduit or 4 ” EMT ( Sleeve Optional ) ( 2-1 / 2 ” Concrete ) ( AS = 0 ” to 1-7 / 8 ”)
Max . 30 ” steel , cast iron , max . 6 ” copper , conduit or max . 4 ” EMT pipe ( 2-1 / 2 ” concrete ) ( AS = 0 ” to 7 / 8 ”)
Tub Box with max . 1-1 / 2 ” brass waste / overflow fittings
Tub Box with max . 1-1 / 2 ” brass waste / overflow fittings
Max . 2 ” Copper , brass , or cast iron waste / overflow fittings ( 2-1 / 2 ” concrete over metal deck ) ( AS = 0 ” to 1-7 / 8 ”)
Max . 1-1 / 2 ” steel , EMT , or steel conduit ; max . 1 ” copper ( Max . Qty 4 )
3 Hr ◼
Max . 6 ” steel , cast iron , steel conduit , max . 4 ” EMT
4 Hr ◼ ◼ or max . 2 ” copper
Max . 10 ” steel , cast iron , max . 6 ” steel conduit , or max . 4 ” EMT 2 Hr ◼ ◼ ◼
Max . 6 ” steel , cast iron , steel conduit , or max . 4 ” EMT ( Unifrax or Thermal Ceramics insulation )
Max . 3 ” steel or cast iron with closet flange ( AS = min 3 / 8 ”)
Max . 8 ” steel , cast iron , max . 6 ” steel conduit , max . 4 ” copper or EMT ( optional sleeve ) ( 2-1 / 2 ” concrete ) ( AS = 0 ” to 2 ”)
Max . 4 ” steel , cast iron , steel conduit , EMT , or 1 ” flexible steel conduit ( one or more )
Max . 6 ” steel , cast iron , steel conduit , copper or 4 ” EMT ( 2-1 / 2 ” to 8 ” Concrete )
Max . 4 ” steel , cast iron , steel conduit , or EMT
Max . 12 ” x 12 ” x 10 ” deep cast iron floor sink with 4 ” cast iron drain ( 2-1 / 2 ” concrete ) ( Thermal Ceramics insulation )
Max 8 ” steel , cast iron , max 4 ” copper , steel conduit , or EMT ( AS = ¼ ” to 1-5 / 8 ”)
Max . 12 ” x 12 ” x 10 ” deep cast iron floor sink with 4 ” cast iron drain ( 2-1 / 2 ” concrete over metal deck ) Utilzes Thermal Ceramics
Multiple Max . 4 ” steel , cast iron , steel conduit , EMT , or 1 ” flexible steel conduit ( one or more & multiple rows ) ( 2 Hour rating T-rating w / Thermal Ceramics or Unifrax Duct Wrap )
Max . 2 ” Steel , Cast Iron , Copper , Steel Conduit or EMT through Concrete Floor or Concrete Hollow- Core Floor
Max 4 ” Steel , Cast-Iron , Ductile Iron , Copper , Conduit , or EMT
One or more max 3 ” Steel , Cast-Iron , Ductile Iron , Copper , Conduit , or EMT ( AS reference table in system )
Max 4 ” Steel , Cast-Iron , Ductile Iron , Copper , Conduit , or EMT
CP 680-M CP 680-P CP 680-PX
CP 680-M CP 680-P CP 680-PX
Concrete Floors / Walls
System Number [ Similar FM Approved System ]
F-A-1022
F-A-1023
2 Hr FS-ONE MAX F-A-1028
2 Hr FS-ONE MAX F-A-1029
3 Hr ◼ CP 681 F-A-1037
3 Hr CP 681 F-A-1038
2 Hr CP 637 F-A-1051
3 Hr
2 Hr ◼ ◼ ◼
CP 680-M CP 680-P CP 680-PX
CP 680-P CP 680-PX
FS-ONE MAX CFS-S SIL GG CFS-S SIL SL
CP 680-P CP 680-PX
F-A-1066
F-A-1091
FA-1105
F-A-1106
2 Hr ◼ FS-ONE MAX F-A-1108
2 Hr ◼
CFS-S SIL GG CFS-S SIL SL
F-A-1119
2 Hr ◼ FS-ONE MAX F-A-1127
3 Hr ◼ ◼ CFS-DID MD F-A-1128
2 Hr ◼ ◼ FS-ONE MAX F-A-1134
2 Hr ◼ ◼ FS-ONE MAX F-A-1135
3 Hr ◼ ◼
CFS-S SIL GG CFS-S SIL SL
F-A-1136
2 Hr ◼ ◼ FS-ONE MAX F-A-1137
2 Hr ◼ ◼ FS-ONE MAX F-A-1168
3 Hr ◼ CFS-DID C F-A-1170
2 or 3 Hr ◼ ◼ CFS-CID MD P , PX , or M F-A-1192
2 or 3 Hr ◼ CFS-CID MD P , PX , or M F-A-1193
2 Hr ◼ ◼ CFS-CID MD P , PX F-A-1194
NEW Max . 10 ” Steel , 10 ” Iron , 6 ” Conduit , 4 ” Copper 2 Hr ◼ ◼ ◼ CFS-CID M 8 ”, 10 ” F-A-1202
Nom . 3 ” or 4 ” steel or cast iron with aerator fitting ( Sovent ) ( 5 ” or 6-1 / 2 ” concrete )
3 Hr
CP 680-M CP 680-P , or CP 680-PX w / aerator adaptor
F-B-1009
