Size Penetrating of Blank Opening Item ( s ) F-Rating T-Rating L-Rating W-Rating Product
MISCELLANEOUS MECHANICAL / DUCTS IN CONCRETE FLOORS / WALLS ( CONTINUED )
Max . 20 ” spiral would duct or 12 ” sheet metal duct ( w / o damper ) with 1-1 / 2 ” thick glass fiber duct insulation ( AS = 1 / 4 ” to 1 ”)
Max . 12 ” x 10 ” sheet metal duct ( AS = 0 ” to 1 ”)
Concrete Floors / Walls
System Number [ Similar FM Approved System ]
1 or 2 Hr FS-ONE MAX W-J-7124
1 Hr
FS-ONE MAX CP 606
Penetrating Item ( s ) F-Rating T-Rating L-Rating W-Rating Product
MIXED PENETRATING ITEMS IN CONCRETE FLOORS / WALLS *
Multiple insulated and non-insulated copper pipes ( max . 3 ”) ( AS = 1 ” to 2-1 / 4 ”)
Multiple insulated and non-insulated steel and copper pipes ( max . 3 ” steel / copper ) ( AS varies )
Insulated and non-insulated steel and copper pipe ( max . 1 ” steel / copper ) ( AS = 3 / 8 ” to 2 ”)
Insulated or non-insulated steel , cast iron , copper , conduit or EMT pipes , cable tray or cables ( single or bundled ) ( AS varies )
Multiple insulated and non-insulated copper pipe , max . 1-1 / 2 ” PVC ( open or closed ) and cables
Max . 6 ” steel tube and cables ( AS varies )
Max . 6 ” steel , cast iron , copper , conduit , or max . 4 ” EMT pipe
Insulated or non-insulated steel , cast iron , copper , conduit or EMT pipes , flexible metal conduit or cables ( single or bundled ) ( AS varies )
Insulated or non-insulated copper or steel , cables ( single or bundled ), or flexible steel conduit ( included Hollow Core ) ( AS varies )
Insulated or non-insulated copper or cables ( single or bundled ) ( AS varies )
Max . 2 ” EMT or conduit , single or bundled cables , max . 2 ” PVC Innerduct ( AS varies )
Max . 8 ” steel , cast iron , 6 ” copper , steel conduit , or max . 4 ” EMT , Max . 2 ” Innerduct , Cable Tray , Large cables , ( various cables ) ( AS varies )
Insulated or non-insulated metallic pipes ; cable bundles ; steel conduits ( max . 48 ” x 30 ” opening ) ( AS varies )
HVAC line set ( sleeve optional ) ( bottom side access ) ( AS varies )
Insulated or non-insulated metallic pipes ; cables , PVC , or CPVC , sheet metal ducts ( AS varies )
HVAC line set w / PVC drain ( AS varies )
Insulated or non-insulated copper or steel , cables ( single or bundled ), or flexible steel conduit ( AS varies )
Insulated or non-insulated steel , cast iron , copper , conduit or EMT pipes , cable tray or cables ( single or bundled ) ( AS varies )
Insulated or non-insulated copper or cables ( single or bundled ) ( AS varies )
Max . 2 ” EMT or conduit , single or bundled cables , max . 2 ” PVC Innerduct ( AS varies )
Max . 8 ” steel , cast iron , 6 ” copper , steel conduit , or max . 4 ” EMT , Max . 2 ” Innerduct , Cable Tray , Large cables , ( various cables ) ( AS varies )
Insulated or non-insulated steel , cast iron , copper , max . 2 ” PVC / CPVC , cables ( AS varies )
Insulated or non-insulated steel , cast iron , copper ( AS varies )
F-E-7008
System Number [ Similar FM Approved System ]
3 Hr FS-ONE MAX C-AJ-8038
3 Hr ◼ FS-ONE MAX C-AJ-8041
3 Hr FS-ONE MAX C-AJ-8044
3 Hr ◼ Firestop Block C-AJ-8056
2 Hr
FS-ONE MAX w / Ret Collar
C-AJ-8058
2 Hr FS-ONE MAX C-AJ-8081
4 Hr ◼ CP 637 C-AJ-8095
2 Hr ◼ Fire Foam C-AJ-8096
3 Hr ◼ FS-ONE MAX C-AJ-8099
3 Hr Firestop Block C-AJ-8100
3 Hr ◼ Firestop Block C-AJ-8107
3 Hr ◼ Firestop Block C-AJ-8110
2 Hr FS-ONE MAX C-AJ-8143
3 Hr FS-ONE MAX C-AJ-8148
2 Hr ◼ CP 637 C-AJ-8166
2 Hr CP643N C-AJ-8177
2 Hr Fire Foam C-AJ-8178
3 Hr ◼ Firestop Block C-AJ-8180
3 Hr Firestop Block C-AJ-8207
3 Hr ◼ Firestop Block C-AJ-8208
3 Hr Firestop Block C-AJ-8209
2 Hr Firestop Block C-AJ-8210
3 Hr CFS-BL C-AJ-8211
