INSULATED PIPES IN CONCRETE FLOOR / WALLS ( CONTINUED )
One or more Max . 7 / 8 ” Streamline ACR-TYPE L Copper Tubing with Nom . ½ ” Polyethylene Insulation ( Max QTY .= 4 )
Max . 8 ” Polypropylene ( PP ) Aquatherm Bluepipe with Nom . 2 ” Cellular Glass Insulation or Nom . 1 ” Glass Fiber Insulation
Max . 20 ” steel pipe with 3 ” thick 8 PCF mineral wool insulation extending above and below floor assembly 6 ”
Max . 4 ” copper with 1 ” thick glass fiber insulation or 3 / 4 ” thick AB / PVC insulation
Max 4 ” Copper with 1 ” thick glass fiber insulation or 3 / 4 ” thick AB / PVC insulation
Max 2 ” copper with 2 ” Glass fiber insulation or 3 / 4 ” thick AB / PVC insulation
Max . 2-1 / 2 ” PP pipe with 1-1 / 2 ” thick glass fiber insulation ( AS = 3 / 8 ” to 1-1 / 8 ”)
Nom . 6 ” copper pipe with 1 ” thick glass fiber insulation or Nom . 4 ” copper pipe with 2 ” thick glass fiber insulation
2 Hr ◼
2 Hr ◼
1 and 1-1 / 2 Hr
CP 648- E FS-ONE MAX
CP 648-E FS-ONE MAX
W-J-5194
W-J-5195
FS-ONE MAX FM 209
2 or 3 Hr CP 680 FM 309
1 / 2 , 1 , 1-1 / 2 , or 2 Hr
CP 680 FM 348
3 Hr CP 680 FM 514
2 Hr ◼
CP 648E FS-ONE MAX
FM 693
2 Hr ◼ CFS-CID-8 ” FM 717
MISCELLANEOUS ELECTRICAL ( BUSWAY ) IN CONCRETE FLOORS / WALLS
Electrical busway ( 23 ” x 4-1 / 2 ”) ( 2-1 / 2 ” concrete )
Electrical busway ( 26 ” x 6 ”)
Electrical busway ( 23 ” x 4-1 / 2 ”, qty 1 ) or ( 11-1 / 4 ” x 4-1 / 2 ”, qty 2 ) ( AS = 1 / 4 ” to 5-3 / 4 ”)
Electrical busway ( 23 ” x 4-1 / 2 ”, qty 1 ) or ( 11-1 / 4 ” x 4-1 / 2 ”, qty 2 ) ( AS = 1 / 4 ” to 5-3 / 4 ”)
Electrical busway ( 23 x 4-1 / 2 ”) ( AS = 1 / 2 ” to 6-1 / 2 ”)
ABS fiber optic cable tray ( 12 ” x 4 ”) ( AS = 0 ” to 4 ”)
3 Hr CP 637 C-AJ-6006
3 Hr FS-ONE MAX C-AJ-6017
2 Hr Fire Foam C-AJ-6036
2 Hr Firestop Block C-AJ-6042
2 Hr
CFS-S SIL GG CFS-S SIL SL
F-A-6002
2 Hr ◼ Firestop Block W-J-6003
Size Penetrating of Blank Opening Item ( s ) F-Rating T-Rating L-Rating W-Rating Product
MISCELLANEOUS MECHANICAL / DUCTS IN CONCRETE FLOORS / WALLS
System Number [ Similar FM Approved System ]
|
Non-Metallic Pipes *
Cables / Cable Trays
Insulated Pipes
Miscellaneous Electrical ( Busway )
Miscellaneous Mechanical / Ducts
Mixed Penetrating Items *
Blank Openings
Metallic Penetrants
Non-Metallic Pipes *
Cables
Cable Trays
Insulated Pipes
Miscellaneus Electrical ( Busway )
Miscellaneous Mecahnical / Ducts *
Mixed Penetrating Items *
Blank Openings
Metallic Penetrations
Non-Metallic Pipes *
Cables
Insulated Pipes
Miscellaneous Mechanical / Duct Penetrations
Mixed Penetrating Items *
Metallic Penetrations
Non-Metallic Pipes *
Cables
Insulated Pipes
Miscellaneous Mechanical / Duct Penetrations
Mixed Penetrating Items *
|
Steel-Framed Floors Wood-Framed Floors Framed ( Gypsum ) Walls
Concrete Floors / Walls
|
||
|
Max . 36 ” grease duct manufactured by Metal-Fab ( AS = 1 ”)
Max . 32 ” x 32 ” sheet metal duct w / o damper ( AS = 1 / 4 ” to 1-1 / 2 ”)
Max . 30 ” x 30 ” sheet metal duct w / o damper ( AS = 1 / 4 ” to 1-3 / 4 ”) Optional : Flamebar duct coating
Max . 20 ” spiral wound or 12 ” sheet metal duct w / o damper ( AS = 0 ” to 1-1 / 2 ”)
Max . 6 ” sheet metal duct w / o damper ( bottom side access )( hollow core ) ( AS = 0 ” to 2 ”)
Max . 24 ” x 12 ” sheet metal duct w / o damper ( bottom side access ) ( AS = 0 ” to 2 ”, point of contact on maximum two adjacent sides )
Max . 30 ” x 30 ” sheet metal duct w / o damper ( AS = 1 / 4 ” to 1-3 / 4 ”)
Max . 60 ” x 36 ” sheet metal duct with 2 ” glass fiber duct insulation ( AS varies )
Max . 8 ” sheet metal duct ( min 26 Ga ) ( AS = ¼ ” to 1-3 / 4 ”)
Max . 8 ” dia sheet metal duct w / o damper ( AS = 0 to 1 ”) ( 8 ” prescast concrete )
|
3 Hr ◼ ◼ FS-ONE MAX C-A-J7006
3 Hr ◼
CFS-S SIL GG CFS-S SIL SL
C-AJ-7046
3 Hr CP 606 C-AJ-7051
2 Hr
FS-ONE MAX CP 601s CP606 CP 604 CFS-S SIL GG CFS-S SIL SL
C-AJ-7084
2 Hr FS-ONE MAX C-AJ-7103
2 Hr FS-ONE MAX C-AJ-7104
2 Hr FS-ONE MAX C-AJ-7111
2 Hr FS-ONE MAX C-AJ-7145
2 Hr
CFS-S SIL GG CFS-S SIL SL
C-AJ-7149
3 Hr ◼ FS-ONE MAX C-BJ-7005
|
