Compaction Engine Dimensions

Drum width ( mm ) Rolling width ( mm ) 2910 2910 3425 3425 3430

Gradeability (%) 100 100 100 100 100

Dozer blade size ( HxW ) ( mm )

1650 x 3000 1650 x 3000 1880 x 3000 1880 x 3800 1880 x 3800

Blade lifting height ( mm ) 1000 1000 1200 1200 1200

Blade digging depth ( mm )

150 150 200 200 200

Wheel base ( mm ) 3350 3350 3500 3500 3500 Ground clearance ( mm ) 435 435 490 490 490

Number of compaction wheels

4 4 4 4 4

Wheel width front ( mm ) 1040 1040 1195 1195 1195 Wheel width rear ( mm ) 835 835 970 970 970

Wheel diameter front ( mm )

Wheel diameter Rear ( mm )

1500 1500 1620 1620 1620

1500 1500 1620 1620 1620

Teeth per wheel - Front 50 50 50 50 50 Teeth per wheel - Rear 40 40 40 40 40

Travel speed - Forward 1 ~ 2 ~ 3

2004 / 07 / 10 2004 / 07 / 10 4.5 / 7 / 10 4.5 / 7 / 10.9 4.5 / 7 / 10.9

Travel speed - Rear 1 ~ 2 4 / 7.7 4 / 7.7 4 / 7.7 4 / 7.7 4 / 7.7 Make Engine make Shangchai Shangchai Shangchai Shangchai Shangchai Model Engine model SC8DK200G3 SC8DK200G3 SC9DK260G3 SC9DK260G3 SC9DK260G3 Net power ( kW @ rpm ) Net power ( Kw @ Rpm ) 147 @ 2200 147 @ 2200 192 @ 2200 192 @ 2200 192 @ 2200 Length ( mm ) Length ( mm ) 7355 7350 8150 8150 8150 Width ( mm ) Width ( mm ) 3000 3000 3650 3650 3650 Height ( mm ) 3600 3600 3800 3800 3800 Power killing pump Flowjet Flowjet Flowjet Flowjet Flowjet

Centralize lubrication system

SKF SKF SKF SKF SKF

Drive axle Fenyi Fenyi Fenyi Fenyi Fenyi Transmission make Hangzhou ( ZF ) Hangzhou ( ZF ) Hangzhou ( ZF ) Hangzhou ( ZF ) Hangzhou ( ZF ) Transmission model 4WG180 4WG180 4WG180 4WG180 4WG180

Infrared LCD , LED vidio monitor system

Shenzhen Shenzhen Shenzhen Shenzhen Shenzhen Distributor South African distributor Earth Mach Earth Mach Earth Mach Earth Mach Earth Mach

Compaction Engine

Dimensions

Make Ammann BOMAG BOMAG Dynapac Wacker Neuson Wacker Neuson Wacker Neuson Model ARW65 BW 65 H BW 75 H DTR75 RD7Af HRC RD7Hf RD7Yehf Operating weight ( kg ) 720 757 1040 760 690 735 710 Type Walk behind roller Pedestrian rollers Pedestrian rollers Smooth Hydrostatic Hydrostatic Hydrostatic Drum width ( mm ) 650 650 750 650 650 650 650 Vibration frequency ( Hz ) 55 55 55 55 46 / 56 46 / 56 46 / 56

Centrifugal force high / low amp ( kN )

13 / 18 22 40 22 22.5 22.5 22.5

Make Hatz Hatz Yanmar Hatz Honda Hatz 1B42 Yanmar Model 1D42S 1D 42 L 100 1D42 GX390 1B42 L48 Net power ( kW @ rpm ) 6.1 6.2 6.2 6.2 / 2800 6.0 @ 2600 6.1 @ 2600 5.6 @ 2600 Length ( mm ) 2288 2320 3010 2200 1351 1351 1351

Width ( mm ) 720 765 865 762 720 720 720 Distributor ELB Equipment Kemach Equipment Kemach Equipment Dynapac Wacker Neuson Wacker Neuson Wacker Neuson

66 EQUIPMENT SPECS HANDBOOK 2023 / 2024 www . equipmentandhire . co . za
