Tandem Rollers
Tandem Rollers
Dimensions Engine Compaction
Make |
Dynapac |
Hamm |
Hamm |
Hamm |
Hamm |
Hamm |
Hamm |
Hamm |
Model |
CC1200 |
HD 8 W |
HD 10 W |
HD 12 W |
HD 13 W |
HD 14 W |
HD 70 |
HD 75 |
Operating weight ( kg ) |
2600 |
1580 |
2450 |
2705 |
3970 |
4345 |
7265 |
7680 |
Type |
Smooth |
Pivoted |
Pivoted |
Pivoted |
Pivoted |
Pivoted |
Pivoted |
Pivoted |
Drum width ( mm ) |
1200 |
800 |
1110 |
1200 |
1300 |
1380 |
1500 |
1680 |
Nominal amplitude |
0.5 |
0.5 / 0.5 |
0.54 / 0.54 |
0.52 / 0.52 |
0.31 / 0.51 |
0.31 / 0.51 |
0.62 / 0.35 |
0.61 / 0.33 |
Vibration frequency ( Hz ) |
58 |
52 / 65 |
52 / 67 |
52 / 67 |
51 / 60 |
51 / 60 |
48 / 58 |
48 / 58 |
Centrifugal force High / low amp ( kN ) |
27 |
16 / 25 |
28 / 46 |
32 / 52 |
39 / 64 |
39 / 64 |
76 / 62 |
76 / 62 |
Make |
Kubota |
Kubota |
Kubota |
Kubota |
Kubota |
Kubota |
Deutz |
Deutz |
Model |
D1703-M |
D1005-E |
D1503-M |
D1503-M |
V2203-M |
V2203-M |
TD2011 |
TD2011 |
Net power ( kW @ rpm ) |
26 ( 35 ) |
14.8 @ 2700 |
22.9 @ 2700 |
22.9 @ 2700 |
34.6 @ 2700 |
34.6 @ 2700 |
63 @ 2500 |
63 @ 2500 |
Length ( mm ) |
2395 |
2260 |
2460 |
2460 |
2860 |
2860 |
4340 |
4340 |
Width ( mm ) |
1310 |
856 |
1110 |
1310 |
1426 |
1506 |
1610 |
1790 |
Articulation either side ( degrees ) |
|
|
|
|
|
|
|
|
Distributor |
Dynapac |
Wirtgen SA |
Wirtgen SA |
Wirtgen SA |
Wirtgen SA |
Wirtgen SA |
Wirtgen SA |
Wirtgen SA |
Compaction Engine
Dimensions
Make Hamm Hamm Hamm Hamm JCB JCB Volvo
Model HD 90 HD 110 HD + 120 HD + 140 CT160-100 CT260-120 DD25 RD27 Operating weight ( kg ) 9190 10540 12845 13340 1790 2560 2515 341
Type Pivoted Pivoted Pivoted Pivoted
Vibratory tandem roller
Vibratory tandem roller
Drum width ( mm ) 1680 1680 1980 2140 1000 1200 1200 1.2 Nominal amplitude 0.65 / 0.36 0.81 / 0.47 0.88 / 0.49 0.35 0,51 0.5 0.5 Vibration frequency ( Hz ) 42 / 50 42 / 50 40 / 50 40 / 50 50 / 66 50 / 66 55 / 66.7 52 / 67 Centrifugal force High / low amp ( kN ) 75 / 59 117 / 97 159 / 138 179 / 138 10.9 / 19.1 23.6 / 41.1 40.6 32 / 52 Make Deutz Deutz Deutz Deutz Kubota Kubota Volvo Kubota
Model TCD2012 TCD2012 TCD2012 TCD2012 D1005-E4B-EU D1703-M-DI- E4B
Net power ( kW @ rpm ) 100 @ 2300 100 @ 2300 100 @ 2300 100 @ 2300 14.2 @ 2550 18.2 @ 2200 18.2 @ 2200 22.9 Length ( mm ) 4600 4600 5000 5000 2140 2490 2540 2460 Width ( mm ) 1810 1810 2545 2705 1090 1295 1290 1310 Articulation either side ( degrees ) +/ - 33 +/ - 33 30 45
Tandem
D1,7A
Wacker Neuson
Hydrostatic
Distributor Wirtgen SA Wirtgen SA Wirtgen SA Wirtgen SA Bell Equipment Bell Equipment Babcock Wacker Neuson
D1503
Make XCMG XCMG XCMG NOTES
Compaction Engine
Dimensions
Model XD123E XD133E XD143 Operating weight ( kg ) 12300 13000 14000
Type
Tandem smooth drum
Tandem smooth drum
Drum width ( mm ) 2130 2130 2130
Tandem smooth drum
Nominal amplitude 0.4 / 0.75 0.45 / 0.80 0.3 / 0.8 Vibration frequency ( Hz ) 48 / 45 48 / 45 50 / 67 Centrifugal force High / low amp ( kN ) 85 / 140 95 / 150 110 / 170 Make Deutz Deutz Deutz Model BF04M2012C BF04M2012C BF04M1013EC Net power ( kW @ rpm ) 92 @ 2100 92 @ 2100 118 @ 2300 Length ( mm ) 5140 5140 5140 Width ( mm ) 2270 2270 2290 Articulation either side ( degrees ) ± 35 ± 35 Distributor XCMG SA XCMG SA XCMG SA
www . equipmentandhire . co . za
EQUIPMENT SPECS HANDBOOK 2023 / 2024
65
