Scissor Lift

Vertical Scissor Lift Scissor Lift

Dimensions

Loading Systems

Make Dingli Dingli Model

GTWY11-1300

AMWP11.5- 8200AC

Max. Working Height( m) 11.00m 11.20m Max. Platform Height( m) 9.00m 9.20m Overall Length( Stowed)( m) 1.34m 2.62m Overall Length( Tilted Back)( mm) Overall Width( Stowed)( mm) Overall Width( m) 0.75m 1.00m Overall Height( Stowed)( m) 1.99m 1.99m Overall Height( Tilted Back)( mm) Outrigger Footprint( Length / Width)( m) 1.70m / 1.86m Platform Size( Length × Width)( m) 0.70m × 0.60m 0.69m × 0.93m Ground Clearance( Stowed)( m) 0.055m 0.07m Ground Clearance( Raised) 0.02m Wheelbase( mm) 1.22m Turning Radius( mm) 0m / 1.8m Tyres( Front)( mm) Φ127 × 50mm φ381 × 127mm Tyres( Back)( mm) Φ203 × 50mm φ381 × 127mm Safe Working Load( kg) 150kg 200kg / 441lb Max. Occupants( Indoor / Outdoor)( Person) 1 / 0 2 or 1 Gradability(°) 0.25 Max. Working Slope( X / Y)(°) 2.5 / 2.5 Turret Rotation(°) 345 ° Jib Movement(°) + 70 °/-60 °

Travel Speed( Stowed)( km / h)

Travel Speed( Raised)( km / h)

5.0km / h / 3.11mph

0.5km / h / 0.31mph

Up / Down Speed( ms) 34 / 2 2sec 42 / 38sec

Overall Weight- AC( kg)

Overall Weight- DC( kg)

450kg

470kg

2970kg / 6548lb

2970kg / 6548lb

Lead-Acid Maintenance-Free Battery( V / AH) 12V / 85Ah 24V / 200Ah Lithium Battery( V / AH)

24V / 180Ah Charger( VDC / A) 12VDC / 15A 24VDC / 30A Lifting Motor- AC( VAC / kW)

220VAC / 1.5kW Lifting Motor- DC( VAC / kW) 12VDC / 1.5kW 15VAC / 3kW

Driving Motor( VAC / kW)

2 × 15VAC / 0.87kW

Fuel / Electricity( AC / DC) Electric Electric Distributor SkyJacks SkyJacks

For the MTE Calendar & Expopedia visit www. MTEexpos. co. za

Dimensions Loading Systems

Store Picker Lift

Make DingLi DingLi Model OPT0507 DYT2-3.7SW Max. Working Height( m) 4.99m 5.70m / 18ft 8in Max. Platform Height( m) 2.99m 3.70m / 12ft 2in Overall Length( Stowed)( m) 1.59m 1.38m / 4ft 6in Overall Length( Tilted Back)( mm) Overall Width( Stowed)( mm) 0.75m 1.06m / 3ft 6in Overall Width( m) Overall Height( Stowed)( m) 1.59m 2.39m / 7ft 10in Overall Height( Tilted Back)( mm) Outrigger Footprint( Length / Width)( m)

Platform Size( Length × Width)( m)

1.11m × 0.80m / 3ft 8in × 2ft 7in

Ground Clearance( Stowed)( m) 0.04m 0.08m / 3in Ground Clearance( Raised) Wheelbase( mm) 1.11m 0.92m / 3ft Turning Radius( mm) 0m / 1.30m Tyres( Front)( mm) Φ254 × 63.5mm Φ152 × 55mm Tyres( Back)( mm) Φ305 × 63.5mm Φ152 × 55mm Safe Working Load( kg) 135kg / 298lb 300kg / 661lb Safe Working Load( kg) Safe Working Load( kg)

90kg / 198lb

115kg / 253lb Max. Occupants( Indoor / Outdoor)( Persons) 1 / 0 1 / 0 Gradability(°) 0.15 0 Max. Working Slope( X / Y)(°) 0 ° 1 °/ 1 °

Forward Speed( Stowed)( km / h)

Back Speed( Stowed)( km / h)

Travel Speed( Stowed)( km / h)

4.80km / h / 2.98mph

3.20km / h / 1.99mph

1.30km / h / 0.81mph

Up / Down Speed( ms) 18 / 18sec 33 / 18sec Overall Weight- AC( kg) Overall Weight- DC( kg) 660kg / 1455lb 580kg / 1279lb Lead-Acid Maintenance-Free Battery( V / AH) 24V / 115Ah 12V / 85Ah Lithium Battery( V / AH) Charger( VDC / A) 24V / 15A 12V / 30A Lifting Motor- AC( VAC / kW) Lifting Motor- DC( VDC / kW) 24VDC / 1.4kW 12V / 1.6kW

Driving Motor( VAC / kW)

2 × 15VAC / 0.68kW

Fuel / Electricity( AC / DC) Electric Electric Distributor SkyJacks SkyJacks
