Scissor Lift
Dimensions
Specifications
Make Dingli Dingli Dingli Dingli Dingli Dingli Model S0808AC + S1008AC + S1012AC + S1212AC + S1412AC + S1614AC + Max. Working Height( Indoor)( m) 8.00m 10.00m 10.00m 12.00m 13.80m 15.70m Max. Platform Height( Outdoor)( m) 6.00m 8.00m 8.00m 10.00m 11.80m 13.70m Overall Length( With Ladder)( m) 2.48m 2.48m 2.48m 2.48m 2.48m 2.84m Overall Width( m) 0.83m 0.83m 1.15m 1.15m 1.19m 1.39m / 4ft 7in Overall Height( Rails Up)( m) 2.23m 2.36m 2.36m 2.49m 2.62m 2.62m / 8ft 7in Overall Height( Rails Down)( mm) 1.77m 1.90m 1.83m 1.96m 2.09m 2.09m / 6ft 10in
Platform Size( Length × Width)( m) 2.27m × 0.81m 2.27m × 0.81m 2.27m × 1.12m 2.27m × 1.12m 2.27m × 1.12m
2.64m × 1.12m / 8ft 8in × 3ft 8in
Platform Extension Size( m) 0.90m / 2ft 11in 0.90m / 2ft 11in 0.90m / 2ft 11in 0.90m 0.90m 0.90m / 2ft 11in
Ground Clearance( Stowed / Raised)( m) 0.10m / 0.019m 0.10m / 0.019m 0.10m / 0.019m 0.10m / 0.019m 0.10m / 0.019m
0.10m / 0.019m / 4in / 1in
Wheelbase( m) 1.87m 1.87m / 6ft 2in 1.87m / 6ft 2in 1.87m 1.87m 2.24m / 7ft 4in
Turning Radius( Inside / Outside)( mm) 0m / 2.10m 0m / 2.10m 0m / 2.10m / 0in 0m / 2.10m 0m / 2.10m
0m / 2.70m / 0in / 8ft 10in
Tyres( mm) φ381 × 127mm φ381 × 127mm φ381 × 127mm φ381 × 127mm φ381 × 127mm φ381 × 127mm Safe Working Load( kg) 408kg / 900lb 272kg / 600lb 450kg / 992lb 408kg / 900lb 408kg / 900lb 363kg / 800lb S. W. L On Extension( m) 113kg / 249lb 113kg / 249lb 113kg / 249lb 113kg / 249lb 113kg / 249lb 136kg / 299lb Max. Occupants( Indoor / Outdoor)( Person) 2 or 1 2 / 0 2 or 2 2 or 1 3 / 0 2 / 0 Gradeability( m) 0.25 0.25 0.25 0.25 0.25 0.25 Travel Speed( Stowed)( km / h) 6.0km / h / 3.73mph 6.0km / h / 3.73mph 6.0km / h / 3.73mph 6.0km / h / 3.73mph 6.0km / h / 3.73mph 6.0km / h / 3.73mph Travel Speed( Raised)( km / h) 0.8km / h / 0.50mph 0.8km / h / 0.50mph 0.8km / h / 0.50mph 0.8km / h / 0.50mph 0.8km / h / 0.50mph 0.8km / h / 0.50mph Max. Working Slope( X / Y)(°) 1.5 °/ 3 ° 1.5 °/ 3 ° 1.5 °/ 3 ° 1.5 °/ 3 ° 1.5 °/ 3 ° 1.5 °/ 3 ° Up / Down Speed( m / s) 30 / 43sec 32 / 34sec 33 / 35sec 54 / 51sec 52 / 52sec 65 / 66sec Overall Weight( Lead-acid Battery)( kg) 2250kg / 4960lb 2325kg / 5126lb 2845kg / 6272lb 3155kg / 6956lb 3380kg / 7452lb 3630kg / 8003lb Overall Weight( Lithium Battery)( kg) 2160kg / 4762lb 2230kg / 4916lb 2750kg / 6062lb 3060kg / 6746lb 3250kg / 7165lb 3500kg / 7716lb Hydraulic Tank( L) 20L / 5.3gal 20L / 5.3gal 20L / 5.3gal 20L / 5.3gal 20L / 5.3gal 20L / 5.3gal Lead-Acid Maintenance-Free Battery( V / AH) AGM Battery( V / AH) 24V / 185Ah 24V / 185Ah 24V / 185Ah 24V / 200Ah 24V / 240Ah 24V / 240Ah Lithium Battery( V / AH) 28.8V / 150Ah 28.8V / 150Ah 28.8V / 175Ah 28.8V / 175Ah 28.8V / 175Ah 28.8V / 175Ah Charger( V / AH) 28V / 30A 28V / 30A 28V / 30A 28V / 30A 28V / 30A 28V / 30A Lifting Motor1( AC / DC) 15VAC / 3.42kW 15VAC / 3.42kW 15VAC / 3.42kW 15VAC / 3.42kW Lifting Motor2( AC / DC) 15VAC / 3.42kW 15VAC / 3.42kW Driving Motor( AC / DC) 2 × 15VAC / 0.87kW 2 × 15VAC / 0.87kW 2 × 15VAC / 0.87kW 2 × 15VAC / 0.87kW 2 × 15VAC / 0.87kW 2 × 15VAC / 0.87kW Fuel / Electric / Hybrid( AC / DC) Lithium Lithium Lithium Lithium Lithium Lithium Max. Working Height( Outdoor)( m) 8.10m / 26ft 7in 11.00m / 36ft 1in Max. Platform Height( Outdoor)( m) 6.10m / 20ft 9.00m / 29ft 6in Max. Occupants( Indoor / Outdoor)( Person) 2 or 1 2 or 1 Distributor SkyJacks SkyJacks SkyJacks SkyJacks SkyJacks SkyJacks
