ELMARK Lighting 2019 Lighting_2019 | Página 499

LAMPS AND COMPONENTS
www.elmarkholding.eu
ACCESSORIES
MAGNETIC BALLAST FOR COMPACT
FLUORESCENT LAMPS (TC-D)
990153008
ELECTRONIC BALLAST FOR
FLUORESCENT LAMPS
MAGNETIC BALLAST FOR
FLUORESCENT LAMPS - TYPE T8
990153818
POWER SUPPLIES
Catalogue number Model
990153818
Watt
(W)
Current
(A) cos
φ Uinput Uoutput Length
(mm) Width
(mm) Height
(mm) Packing/Box
(pcs)
BALLAST 18W 1X18W 0,370 0.32 230VAC 230VAC 155 41 32 1/50
990153008 BALLAST * 18 0,220 0.48 230VAC 230VAC 105 41 26 1/50
99EB0218 EB218 * 2Х18 T8 - - - 274 27 27 1/50
99EB0236 EB236 * 2Х36 T8 - - - 320 32 28 1/50
99EB0418 EB418 * 4X18 T8 - - - 330 33 29 1/50
99EB0114 EB114 * 1X14 T5 - - - 274 27 27 1/50
99EB0214 EB214 * 2Х14 T5 - - - 250 25 25 1/50
99EB0128 EB128 * 1X28 T5 - - - 274 27 27 1/50
99EB0228 EB228 * 2Х28 T5 - - - 250 25 25 1/50
99EB0135 EB135 * 1X35 T5 - - - 320 30 27 1/50
99EB0235 EB235 * 2X35 T5 - - - 322 30 27 1/50
99EB0149 EB149 * 1X49 T5 - - - 320 30 27 1/50
* 2 year warranty
50Hz
3+0
EEI=B2
standard
+extended
3
YEAR TOTAL
WARRANTY
899
IP20
