ELMARK Lighting 2019 Lighting_2019 | Seite 406

OUTDOOR
FLOODLIGHTS
www.elmarkholding.eu
IP65
SIRIUS SMD
806
Catalogue number Model Watt
(W) Whole fixture
lumens (lm) Colour temp.
(K) Colour body Length
(mm) Width
(mm) Height
(mm) Packing/Box
(pcs)
98SIRIUS50SMD SIRIUS50SMD 50 5000 6500 black 137 35 170 1/10
98SIRIUS100SMD SIRIUS100SMD 100 10000 5500 black 310 80 430 1/10
98SIRIUS150SMD SIRIUS150SMD 150 15000 5500 black 310 80 430 1/10
98SIRIUS200SMD SIRIUS200SMD 200 20000 5500 black 386 106 560 1/10
98SIRIUS250SMD SIRIUS250SMD 250 25000 5500 black 386 106 560 1/10
98SIRIUS300SMD SIRIUS300SMD 300 30000 5500 black 386 106 560 1/10
SIRIUS200SMD
SIRIUS150SMD
Energy class
Body: Aluminium | LED driver: mounted in the body | Light source: 2835SMT Epistar | Input voltage: 100V-240V AC | Ambient Temperature: -30°C÷ +65°C
Material: PC
Material: Polypropylene 94-V2 grade
Rated operational voltage:AC250V
Voltage: 450V
Sunscreen Rating:Sun Protection(UV)
Rated operational Ampere(A):≤30A
Rated current: 6A
Voltage: 450V
Material: flame retardant/Anti UV nylon(PA66)
Wiring Capacity: 0.5-4.0mm2
Rated current: 10A
Crimping terminals:Nickle-plated brass
Terminal Blocks: 3p screw type
Withstand voltage(normal temperature):3KV
Cat. Number: 31071
Metal Part:Plated Brass/Steel Spring
Operating remperature range: -40°C~+105°C
Wiring Capacity: 0.5-2.5mm2
Wiring Capacity: 0.5-2.5mm2
Terminal box IP44
50/60
Hz
Terminal box IP65
SMD
Ra>70 3
Cat. Number: 31070
Cable connector IP68
5+0
standard
+extended
5
Cat. Number: 31072
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
