OUTDOOR
LUMINAIRES
www.elmarkholding.eu
IP65
BELLA with LED Tubes Т8 ELMARK ECO
Catalogue number Watt
(W) Whole fixture
lumens (lm) Colour temp.
(K) Colour body Length
(mm) Width
(mm) Height
(mm) Packing/Box
(pcs)
9BM110LEDCW 1X10 800 6200-6500 grey 670 86 100 1/12
9BM110LED 1X10 800 4000-4300 grey 670 86 100 1/12
9BM118LEDCW 1X18 1440 6200-6500 grey 1270 86 100 1/9
9BM118LED 1X18 1440 4000-4300 grey 1270 86 100 1/9
9BM124LEDCW 1X24 1920 6200-6500 grey 1570 106 110 1/6
9BM124LED 1X24 1920 4000-4300 grey 1570 106 110 1/6
9BM210LEDCW 2X10 1600 6200-6500 grey 670 131 100 1/9
9BM210LED 2X10 1600 4000-4300 grey 670 131 100 1/9
9BM218LEDCW 2X18 2880 6200-6500 grey 1270 131 100 1/6
9BM218LED 2X18 2880 4000-4300 grey 1270 131 100 1/6
9BM224LEDCW 2X24 3840 6200-6500 grey 1570 166 110 1/4
9BM224LED 2X24 3840 4000-4300 grey 1570 166 110 1/4
Energy class
IP65
BELLA with LED Tubes Т8 ELMARK ECO and emergency kit
790
Catalogue number Watt
(W) Whole fixture
lumens (lm) Colour temp.
(K) Colour body Length
(mm) Width
(mm) Height
(mm) Packing/Box
(pcs)
9BM218LEDCWE 2X18 2880 6400 grey 1270 131 100 1/6
9BM218LEDE 2X18 2880 4000 grey 1270 131 100 1/6
9BM224LEDCWE 2X24 3840 6400 grey 1570 166 100 1/4
9BM224LEDE 2X24 3840 4000 grey 1570 166 100 1/4
Energy class
1/4
with LED tubes ELMARK ECO
We offer the fixtures as
per personal request
with a fixed block
and battery with a
possibility for work in
an emergency regime
up to three hours.
Lighting fixtures BELLA
are also available with inox
clips. Catalogue number:
9BICLIPS (2pcs set)
Need sets: BELLA 1x10
(2 sets) 1x18 (4 sets); 1x24
(5 sets) 2x10 (2 sets); 2x18
(4 sets); 2x24 (5 sets)
Wire and fittings
for hanging
mounting 2,5m
2 pcs/ pack
92ACC03
Body: polycarbonate (PC) | Diffuser: polycarbonate (PC) | Reflector: steel white | Ballast: fixed inside the body | Clamps: polycarbonate | Cable gland, metal clips for wall fixing.
50/60
Hz
Ra>80
>20000
3
3+0
standard
+extended
3
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
