OUTDOOR
FACADE AND GROUND
www.elmarkholding.eu
96TOMMYELSP/BL
MINI TOMMY EL
96TOMMYEL/BL
IP66
Resin
MINI TOMMY EL / MINI TOMMY ELSP
Catalogue number Description Watt
(W) Whole fixture Colour temp. Colour Diameter Width
lumens (lm) (K)
(mm)
(mm) Height
(mm) Lampholder Packing/Box Energy class
(pcs)
96TOMMYEL/BL GROUND/WALL FIXTURE 3.5 400 4000 black 122 118 127 1xGU10
1/30
96TOMMYEL/GR GROUND/WALL FIXTURE 3.5 400 4000 gray 122 118 127 1xGU10
1/30
96TOMMYELSP/BL SPIKE GROUND FIXTURE 3.5 400 4000 black 122 118 310 1xGU10
1/30
96TOMMYELSP/GR SPIKE GROUND FIXTURE 3.5 400 4000 gray 118 310 1xGU10
1/30
122
Body material: Resin | UV resistant | Lamp not included| Fully adjustable position
The product is accomplished with a LED bulb which parameters are noted in the chart. If you need any other color
temperature or power, we suggest you to purchase the variants compatible to this fixtures separately as follows:
99LED729 GU 10 LED SMD 6.5W 4000K | 99LED730 GU 10 LED SMD 6.5W 2700K | 99LED796 GU 10 LED SMD 6.5W 6400K
99LED733 GU 10 LED SMD RED | 99LED734 GU 10 LED SMD BLUE | 99LED735 GU 10 LED SMD GREEN
50/60
Hz
Ra>80
>15000
3
3+2
standard
+extended
5
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 45 days.
775
MINI TOMMY ELSP
