INDOOR
LED FIXTURES
www.elmarkholding.eu
LITE
SENSOR LIGHT
95LITE12LED
95LITE24LED
632
99DS401
SHINE SHINE
95SHINE16LED 95SHINE36LED
IP40
LITE / SHINE
Catalogue number Watt
(W) Whole fixture lumens
(lm) Colour temp.
(K) Colour body IP code Length
(mm) Width
(mm) Height
(mm) Packing/Box
(pcs)
95LITE12LED 12 960 4000 white 40 250 250 100 1/20
95LITE24LED 24 1920 4000 white 40 350 350 100 1/10
99DS401 12 800 4000 white 40 290 290 80 1/10
95SHINE16LED 16 1040 4000 white 40 330 330 107 1/10
95SHINE36LED 36 2340 4000 white 40 480 480 115 1/5
detail SHINE 16W / 36W
Body: polycarbonate | LED driver: mounted in the body | Light source: EPISTAR
95DS401 - Detection Distance: max. 6m (<24°), Time Delay: 10 sec ± 3 sec to 3 min ± 30 sec (adjustable), Ambient Light: < 3-2000LUX
50/60
Hz
SMD
Ra>80 3
3+2
standard
+extended
5
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
Energy class
