INDOOR
www.elmarkholding.eu
LED FIXTURES
TRACY SUPER SLIM
95TRACYLEDS20
95TRACYLEDS32
TRACY SUPER SLIM
95TRACYLED20
95TRACYLED32
95TRACYLED42
TRACY SUPER SLIM
95TRACYLED80
631
TRACY SUPER SLIM
Catalogue number Watt
(W) Whole fixture lumens
(lm) Colour temp. Colour body
(K) IP code Length/Diameter Width
(mm)
(mm) Height
(mm) Packing/Box
(pcs)
95TRACYLED20 20 1400 4000 white 20 290 - 65 1/10
95TRACYLED32 32 2400 4000 white 20 390 - 65 1/10
95TRACYLED42 42 2950 4000 white 20 480 - 65 1/10
95TRACYLEDS20 20 1400 4000 white 20 280 280 60 1/10
95TRACYLEDS32 32 2400 4000 white 20 330 330 65 1/10
95TRACYLED80 80 6000 4000 white 20 790 - 108 1/1
Material: Metal bottom and MS cover | LED driver: mounted in the body | Light source: 2835 SMD
50/60
Hz
SMD
Ra>80 3
3+2
standard
+extended
5
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
Energy class
IP20
