INDOOR
www.elmarkholding.eu
LED PANELS
LED PANEL ROUND OM
99xLED628
99xLED627
99xLED627CW
LED PANEL ROUND OM
99XLED623
99XLED622
99XLED622CW
LED PANEL ROUND OM
99XLED626
99XLED625
99XLED625CW
IP40
Catalogue number Watt
(W) Whole fixture lumens
(lm) Colour temp.
(K) Colour body Diameter
(mm) Height
(mm) Packing/Box
(pcs)
99XLED626 12 840 2700 white 165 32 1/30
99XLED625 12 840 4000 white 165 32 1/30
99XLED625CW 12 840 6500 white 165 32 1/30
99XLED623 18 1350 2700 white 219 32 1/20
99XLED622 18 1350 4000 white 219 32 1/20
99XLED622CW 18 1350 6500 white 219 32 1/20
99XLED628 24 1800 2700 white 295 32 1/20
99XLED627 24 1800 4000 white 295 32 1/20
99XLED627CW 24 1800 6500 white 295 32 1/20
Voltage: 185-240V | Body: aluminium | Starting time: <0.5s | Power factor: λ>0.8
OM - surface mounted luminaire
50/60
Hz
SMD
120
Ra>80
>10000
40
2+0
standard
+extended
2
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
YEAR TOTAL
WARRANTY
Energy class
619
LED PANELS ROUND OM STELLAR
