178
S ilent series interpreter booths
6300 silent series , ISO 4043:1998
Ref. P1483
External dimensions in mm
W 1720 x D 1720 x H 2280
incl. ventilation and adjustable feet
Internal dimensions
W 1600 x D 1600 x H 2000
Weight incl. safety glass and table
340 Kg
Colour
Light grey (approx. RAL 7042)
Other colours available on request
Sound insulation capacity
Better than ISO 4043:1998
According DIN 56924*
Number of booth parts incl. table and floor
13
Table dimensions in mm
1600 x 500
Including floor
yes
Ventilation Included
Optional
Extension sets to 3 or 4 person booth
* DIN 56924 approved only when the optional double glass is mounted
Adjustable feet Ventilation A
Rear view Cable passage
Silent series sound insulation capacity - ISO 4043:1998
9300 silent series , 1 person booth
Ref. P4019
Type
External dimensions in mm
Weight incl. safety glass and table
1 person booth
W 814 x D 1682 x H 2041 excl. ventilation
150 Kg
ACCESSORIES
F lightcases
Transport your interpreter
booth nice and safe in a
Audipack flightcase.
Ref.
Suitable for Booth
Description
5604+5887 15645
6300
Set of 2
9600
Front loader
17495
8969
9300 1 person (P4019) 9700
Front loader
Front loader (standing model)
A ssembly aid
Ref.
P1866
www.audipack.com
