Easikit Catalogue from Coveya Coveya Easikit catalogue | Page 37

HEAVY DUTY BELT JOINING (R2) EK600 752 EK1200 754 EK1500 755 EK900 753 100 761 250 762 2000 763 EK450 771 EK600 772 EK900 773 H/D 778 EK1200 774 EK1500 775 30m Roll 770 Price code R2 installation tool Easy-to-use, portable tools that make m ultiple rivet driving simple and fast. The MSRT tool holds the belt, fastener strip and the SR700 guide blocks (included) securely in place.Two rivets can be driven simultaneously. Plus, each guide block holds enough rivets to install four fastener plates before reloading. Includes SR700 guide block and SR759 drive rod. R2 clip joint The SR™ (Self-Setting Rivet) fastener utilises staggered pattern, multiple rivet attachments that pass between carcass fibres without severing them. The specially shaped head of each pilot nail works in conjunction with the installation tool anvil plate to set the rivets. The same hammer blows that set the rivets also compress the fastener plates into the belt covers. This provides maximum holding ability and distributes splice tension evenly across the width of the belt. Fasteners Unique two teeth/two rivet combination offers highest efficiencies in strength and durability for heavy-duty applications. Boxed as individual joints. Hinge pin and rivets sold seperately. Installation tool is required. Rivets Belt width Rivets required Rivets are available in either for one joint steel or stainless steel. Rivets 18” 450mm 40 are packaged 250 rivets per 24” 600mm 52 box. SRA rivets are also available in 100-count 36” 900mm 80 packages. Bulk packs of 48” 1200mm 108 2,000 rivets are also available 60” 1500mm 136 in reusable plastic buckets. Hinge pin cable Galvanised steel cable strands are protected by a nylon covering which lubricates fastener loops and helps to hold the pin in place. Heavy Duty hinge pin retaining washers Retaining washers prevents migration of nylon-covered cable hinge pins. Check hinge pins frequently during the first few hours of operation to determine whether migration is a problem in your application. 780 The R2 economy installation tool Price code 785 R2T tool The economically priced R2 Fastener application tool is lightweight and portable, so it is ideal for quick repairs. The six pound R2 tool installs up to 12” (300 mm) of R2 fasteners in one pass. For wider belts, simply move the tool over. EK450 751 Multiple rivet driving tools For use with standard SR TM self-setting rivets and a two pound hammer. R2 economy joint kit Economy kit This kit contains everything needed to make a joint. Kit consists of: • One economy rivet tool • One set of R2 fasteners • Hinge pin • Rivets EK450 791 EK600 792 EK1200 794 EK1500 795 EK900 793 37
