HEAVY DUTY modular support stand
and stringer system
Constructed from galvanised modular 75mm x 50mm x 3mm ‘C’ section with
angle cross bracing. The H/D stands are provided with pre-drilled holes to work in
conjunction with EASIKIT clamp system for extra stabilisation. Stand heights can
be varied by cutting ‘C’ section to suit application.
Stand
Height
No. to underside
1 H/D
Heavy duty stands
combination
340mm
Foot only
450 Price code
600 900 1200
250 250 250 250
2 H/D 1.32m 1 x 1.2m section 251 261 271 241
3 H/D 2.52m 1 x 2.4m section 252 262 272 242
4 H/D 3.72m 1 x 1.2m & 1 x 2.4m section 253 263 273 243
5 H/D 4.92m 254 264 274 244
6 H/D 6.12m 1 x 1.2m & 2 x 2.4m section 255 265 275 245
2 x 2.4m section
Support stands for EK1500 are also available
Support stringers
Stand 4
Fitted to the underside of the conveyor frame in modular 1.2m and 2.4m lengths.
Provides adequate support for spans of up to 6m centres (depending on loading).
Constructed from galvanised ‘C’ section, thus increasing conveyor frame height
by 75mm. This can also be used as a cable tray.
Stand 3
Conv length Price Code
Stand 2
Stand 1
Ex-stock availability
Adaptable modular design
Simple assembly
Robust galvanised construction
Same day parts despatch
The heavy duty modular support system is a cost effective, combined design.
The pre-drilled beams used for the stands are also used for the support stringers.
These stringers are used to provide additional support when longer spans
are needed (up to 6m). The stands utilise a modular design with cross
bracing for heights up to 6m or higher, depending on site conditions.
Support stringers
Conv length Price Code
2.86m
4.06m
5.26m
6.46m
7.66m 280
281
282
283
284 14.86m
16.06m
17.26m
18.46m
19.66m 290
291
292
293
294
8.86m
10.06m
11.26m
12.46m
13.66m 285
286
287
288
289 20.86m
22.06m
23.26m
24.46m
25.66m 295
296
297
298
299
