MINIMILL Typ ZH28 Nut- und Formzirkularfräsen Fräserschaft Stahl Bohrungs-Ø ab 25 mm
groove milling by circular
interpolation toolholder steel bore Ø from 25 mm
DS
d h6
ZH28. ..... .A.ST
(DIN 1835 A)
ZH28. ..... .B.ST
(DIN 1835 B)
ZH28. ..... .E.ST
(DIN 1835 E)
t max.
innere Kühlmittelzufuhr
through coolant
d1
20 14 100 35.7
Bestellbeispiel:
ZH28.2014.35.A.ST
310
M5-MM
T 20F
order-example:
ZH28.2014.35.A.ST
7.0 Nm
Z25
Z28
Z628
Z32
Z635
ZH28.2014.35.A.ST /...B.ST
für
10.7
drehmoment
70 14 13 ZH28.1314.10.A.ST
dimensions and describtions are
valid for all variations
Abmessungen und Beschreibungen
gelten für alle Varianten
