MINIMILL
Übersicht
Nut- und Formzirkularfräsen
summary
Schneidplatten
Nutfräsen
inserts
groove milling
Maße
dimensions
Seite
page
Typ Z33 Nutfräsen allgemein groove milling general use D min. 33
t max. = 10 / 12 ... 333
Typ Z635 / Z635.X Nutfräsen allgemein groove milling general use D min. 35
t max. = 10 ... 334
Typ Z637 / Z640 Nutfräsen allgemein groove milling general use D min. 37 / 40
... 335
t max. = 12 / 13.5
Typ Z637 / Z640 Nutfräsen, Trennfräsen und
Schlitzfräsen, b = 0.4 - 0.8 mm for groove and keyway milling
b = 0.4 - 0.8 mm D min. 37 / 40
... 336
t max. = 12 / 13.5
Typ Z12 Vollradius full radius D min. 12
t max. = 2.5 ... 337
Typ Z16 Vollradius full radius D min. 16
t max. = 3.5 ... 338
Typ Z18 Vollradius full radius D min. 18
t max. = 3.5 ... 339
Typ Z22 Vollradius full radius D min. 22
t max. = 4,5 ... 340
Maße
dimensions Seite
page
Schneidplatten
Gewindefräsen
inserts
thread milling
Typ Z610 metrisches ISO-Gewinde,
innen Teilprofil metric ISO-thread milling,
internal partial profile D min. 10 ... 341
Typ Z12 metrisches ISO-Gewinde,
innen Teilprofil metric ISO-thread milling,
internal partial profile D min. 12 ... 342
Typ Z614 metrisches ISO-Gewinde,
innen Teilprofil metric ISO-thread milling,
internal partial profile D min. 14 ... 343
Typ Z16 metrisches ISO-Gewinde,
innen Teilprofil metric ISO-thread milling,
internal partial profile D min. 16 ... 344
Typ Z18 metrisches ISO-Gewinde,
innen Teilprofil metric ISO-thread milling,
internal partial profile D min. 18 ... 345
Typ Z618 metrisches ISO-Gewinde,
innen Teilprofil metric ISO-thread milling,
internal partial profile D min. 18 ... 346
Typ Z18 metrisches ISO-Gewinde,
innen Vollprofil metric ISO-thread milling,
internal full profile D min. 18 ... 347
groove milling by circular
interpolation
297
