SYSTEM Ztp
System / system ZTP
Wendeschneidplatte für die Schwerzerspanung
System ZTP. ... 20-D
ohne Spanleitstufe Einstechen mit
zweischneidigen Wendeplatten
indexable insert for heavy duty groove
type ZTP. ... 20-D
with flat chipbreaker grooving with two-cutting
edges indexable inserts
X
x
29.90
r
3°
6.3
H
3°
r
10°
6°
16°
10° = position in toolholder
Abmessungen in mm dimensions in mm
Freiwinkel
clear angel
Unten
hinten
lower
H rear
r
ZTP.0200.20-D 7.90 2.0 5° 3° 0.2 .2-D 2.0 - 3.0
ZTP.0300.20-D 7.90 3.0 5° 3° 0.2 .3-D 3.0 - 4.0
ZTP.0400.20-D 7.90 4.0 5° 3° 0.2 .4-D 4.0 - 5.0
ZTP.0500.20-D 7.90 5.0 5° 3° 0.2 .5-D 5.0 - 5.5
ZTP.0600.20-D 7.50 6.0 5° 3° 0.4 .6-D 5.6 - 6.3
Weitere HM Sorten können Sie in der Sorten-
übersicht im Kapitel »Technische Hinweise« und
der Preisliste finden. More carbide grades you can find in the grades
summary in the chapter »technical instructions«
and in the price list.
Bestellbeispiel:
für Sorte AL41F:
ZTP.0200.20-D/AL41F order-example:
grade AL41F:
ZTP.0200.20-D/AL41F
10° = Lage im Klemmhalter
Endziffern
inserts can be used in RH and LH
toolholders as well as in boring bars
WSP sind in R und L Klemmhaltern
sowie Bohrstangen verwendbar
212
220
225
0.428
Spannbereich
holding
Für Halter-Typ:
for toolholder
type:
199
