summary
TIPP!
System / system ZTP Stechdreh-werkzeuge
Stechdreh-Werkzeuge mit
zweischneidigen Wendeplatten Einstechen mit
zweischneidigen Wendeplatten
grooving tools with two-cutting
edges indexable inserts grooving with two-cutting
edges indexable inserts
Wendeschneidplatten grooving insert for Abstechen
bis Ø 50 mm
2 - 4 mm Stechbreite parting-off
up to Ø 50 mm
width of groove 2 - 4 mm . . . 203
Schwerzerspanung
Typ ZTP…34-D
mit Spanformer
Einstechen und
Längsdrehen heavy duty groove
type ZTP…34-D
with chipformer -
grooving and turning . . . 204
Typ ZTP (Axial)
mit Spanformer face grooving
type ZTP
with chipformer . . . 205
Technische Hinweise Technical instructions Hartmetallsorten und
Beschichtungen Carbide grade and coatings . . . 206
Schnittdaten cutting data . . . 208
Übersicht
165
