The Model AR-3A Repeater, UL Listed 864 Accessory Device, is an addressable
bi-directional repeater which is used to form a cellular reception network which
receives, screens, verifies, and retransmits low power radio signals from other CWSI
wireless initiating devices, repeaters and control panels. In addition to providing RF
signaling within the installation the AR-3A provides supervised addressable NACs.
The RB Relay Box is an optional accessory for connection to the AR-5 and AR3A repeater. It provides up to 40 normally open dry contact outputs. The number
of relays corresponds to the model number of the unit for example RB-10 is a ten
relay box. The relay box is ideal for interconnection to Dialers, Elevator Recall,
HVAC Control, and manufacturer’s equipment when other control interfaces are
required. These can be ordered in increments of ten relays.
The Model 310 Manual Fire Alarm Pull Station is a self contained addressable
dual action lexan fire pull station with a built in transmitter. It is UL Listed 38 and
complies with ADA requirements of maximum pull force.
The Model 301/302 Smoke Detectors are state-of-the-art wireless addressable
photoelectric smoke detectors, which incorporate a unique protocol not produced
by other manufacturers. The Model 301 is the industry’s first addressable,
wireless, interconnected tandem smoke detector. In addition to their performance
features, the models 301/302 are supervised for low battery, tamper, pre-alarm
maintenance, and 200 second polling. The protocol also provides for the industry’s
first bi-directional communication between the transmitter and smoke detector,
allowing for hardware fault supervision of the detector itself. The Models 301/302
are UL Listed 268 for use in both commercial and residential applications and are
designed for open area protection.
The Model 340/340TS Fire Transmitters are addressable transmitters designed
specifically for connection to initiating devices, sprinkler flow and supervis
