NEW HYBRID SLIDING SYSTEM FOR HIGH RISE BUILDINGS
Designed to future-proof for an ageing population , more extreme weather conditions and increasingly noisy , high-rise cities , TECHNAL has launched TIGAL . This new , hybrid sliding aluminium system combines the advantages of a sliding door with the high performance of a window , and is especially suitable for tall buildings .
» DESIGNED TO PROVIDE QUIET , comfortable surroundings for occupiers whilst performing well in challenging high-rise conditions , TECHNAL has paid particular attention to TIGAL ’ s design . Combining sleek lines and concealed hardware , it delivers a balanced aesthetic that won ’ t detract from the overall design intent of the building .
UP TO FOUR TIMES MORE WATERTIGHT THAN TRADITIONAL SLIDING DOOR
This hybrid system combines multi-point locking around the perimeter and its patented central sealing system guarantees exceptional water-tightness performance – up to four times better than a traditional sliding door . The action of turning the door handle releases pressure from the perimeter gaskets integrated around the door opening and when closing , the mechanism compresses the door against the gaskets . This seals it tightly to provide E1200 water-tightness and up to Class 5 wind resistance of 3000 Pa .
‘ Purposefully designed for great ease of use ’
GOOD ACOUSTIC AND THERMAL PERFORMANCE
Delivering excellent sound proofing up to 45dB , which is ideal acoustically for an urban environment , the system also offers high thermal performance with U values up to : 0.85 W / m2K ( Ug : 0.5 W / m2K ).
HIDDEN MICRO-VENTILATION INNOVATION FOR NATURAL AIRFLOW
Particularly suited where doors are installed at height and exposed to potential high pressures , TECHNAL has designed an inward ‘ Pull Slide ’ opening mechanism that provides an interesting alternative to the traditional in these situations .
Unlike a conventional sliding door , the door pulls 6mm internally and will sit in either a parallel secure fixed position or slide open , quietly and smoothly along its track . In the micro ventilation position this creates a hidden ventilation gap to all four sides allowing a gentle , well-dispersed airflow internally .
Accessibility has been carefully considered too with TIGAL featuring a recessed threshold and disabled access threshold of 15mm high , purposefully designed for ease of use .
RESPONSIBLY DESIGNED FOR SUSTAINABILITY
Also designed with sustainability in mind , 70 % of the materials and components of TIGAL are recyclable and durable . The extrusion of its aluminium profiles can be produced with Hydro CIRCAL 75R , recycled low carbon aluminium . That means it ’ s prime quality aluminium made with a minimum of 75 % recycled end-of-life aluminium ( post consumer scrap ). Hydro CIRCAL has one of the smallest CO2 footprints worldwide : 2.3 kg of CO2 per kilo of aluminium . This makes TIGAL a much more sustainable model , taking into account that the average carbon footprint of aluminium in Europe is around 8kg .
LARGE DIMENSIONS MAXIMISE LIGHT OPPORTUNITY
Floor-to-ceiling glazing is possible up to a height of 2.70 m and width of 4 m using one sliding and one fixed leaf , with each pane capable of weighing up to 300kg and carrying a glazing thickness of up to 52mm .
Always looking to meet the changing demands of construction in the UK , Allan Barr , TECHNAL UK Sales Director commented on the launch of TIGAL : “ Tall buildings are becoming more and more important for cities of the future . TIGAL introduces innovations that meet the daylighting , ventilation and safety challenges of what can be a demanding but increasingly prevalent environment , putting the comfort of building users first .
“ Purposefully designed for great ease of use , TIGAL ’ s secure micro-ventilation system and smooth , silent operation , provides a serious option for architects designing tall buildings in situations where a high performance door solution is required .”
TECHNAL is part of Hydro , a world leader in aluminium solutions . It shares its values and commitment , namely the preservation of natural resources , the reduction of CO2 emissions and waste , the guarantee of employee safety , the satisfaction of quality expectations and the improvement of consumers ’ quality of life . As part of our commitment , we hold BES 6001 Responsible Sourcing of Construction Products accreditation .
