ASIA DEWALT Catalogue _R01(2021-2022) | Page 33

60V MAX * CORDLESS TOOLS
60V MAX * LITHIUM ION BRUSHLESS 216mm MITRE SAW
DCS777T2
Voltage
60V
Battery Chemistry
Lithium Ion
Battery Capacity
6.0 Ah
No Load Speed
6300 rpm
Blade Diameter
216 mm
Blade Bore Diameter
30 mm
Bevel Capacity
48 °
Mitre Capacity [ Right / Left ]
50 / 50 °
Cutting Capacity at 90 °/ 90 ° ( W x H )
270 x 60 mm
Cutting Capacity at 90 °/ 45 ° ( W x H )
173 x 62 mm , 270 x 48 mm
Cutting Capacity at 45 °/ 90 ° ( W x H )
190 x 60 mm
Max . Cutting Capacity at 45 °/ 45 °
190 x 48 mm
Max . Depth of Cut [ Saws ]
80 mm
Weight
15 kg
Length x Height
490 x 590 mm
2X60V MAX * LITHIUM ION BRUSHLESS 305mm MITRE SAW
DHS780T2
Voltage
2X60V
Battery Chemistry
Lithium Ion
Battery Capacity
6.0 Ah
No Load Speed
3800 rpm
Blade Diameter
305 mm
Blade Bore Diameter
30 mm
Bevel Capacity
49 / 49 °
Mitre Capacity [ Right / Left ]
60 / 50 °
Cutting Capacity at 90 °/ 90 ° ( W x H )
303 x110 mm , 345 x 76 mm
Cutting Capacity at 90 °/ 45 ° ( W x H )
211 x 112 mm , 244 x 76 mm
Cutting Capacity at 45 °/ 90 ° ( W x H )
268 x 63 mm , 345 x 44 mm
Max . Cutting Capacity at 45 °/ 45 °
212 x 76 mm
Max . Depth of Cut [ Saws ]
170 mm
Weight
27.6 kg
Length x Height
770 x 396 mm
NEW
60V MAX * CORDLESS TOOLS
ALSO AVAILABLE AS :
ALSO AVAILABLE AS :
AH
DCS777N
AH
DHS780N
60V MAX * LITHIUM ION BRUSHLESS 250mm MITRE SAW
DCS778T2
60V MAX * LITHIUM ION BRUSHLESS 230mm CUT-OFF SAW
DCS690X2
Voltage
60V
Battery Chemistry
Lithium Ion
Battery Capacity
6.0 Ah
No Load Speed
4300 rpm
Blade Diameter
250 mm
Blade Bore Diameter
30 mm
Bevel Capacity
48 °
Mitre Capacity [ Right / Left ]
50 / 50 °
Cutting Capacity at 90 °/ 90 ° ( W x H )
305x85 mm
Cutting Capacity at 90 °/ 45 ° ( W x H )
305 x 58 mm
Cutting Capacity at 45 °/ 90 ° ( W x H )
215 x 85 mm
Max . Cutting Capacity at 45 °/ 45 °
215 x 58 mm
Max . Depth of Cut [ Saws ]
85 mm
Weight
16.8 kg
Length x Height
615 x 390 mm
Voltage Battery Chemistry Battery Capacity No Load Speed Blade Diameter Blade Bore Diameter Max . Depth of Cut Water Pipe Connection Weight Length x Height
60V Lithium Ion 9.0 Ah 6600 rpm 230 mm 22.2 mm 83 mm Yes 6.25 kg 640 x 250 mm
ALSO AVAILABLE AS :
ALSO AVAILABLE AS :
AH
DCS778N
DCS690N
DCS690B
66 67
