60V MAX * CORDLESS TOOLS |
60V MAX * LITHIUM ION BRUSHLESS 30mm 3 MODE SDS-PLUS ® HAMMER
DCH334X2
Voltage |
60V |
Battery Chemistry |
Lithium Ion |
Battery Capacity |
9.0 Ah |
Tool Holder |
SDS-Plus |
Max . Impact Energy |
4.2 J |
Impact Energy ( EPTA 05 / 2009 ) |
3.5 J |
No Load Speed |
0-1000 rpm |
Blows Per Minute |
0-4480 bpm |
Optimum Drilling Capacity [ Concrete ] |
6-20 mm |
Max . Drilling Capacity [ Concrete / Wood / Metal ] 30 / 30 / 13 mm |
Chipping Mode |
Yes |
Weight |
5.1 kg |
Length x Height |
419 x 250 mm |
Vibration Level |
7.5 m / s ² |
|
|
|
60V MAX * LITHIUM ION BRUSHLESS 48mm SDS-MAX ® COMBINATION HAMMER
DCH733X2
Voltage |
60V |
Battery Chemistry |
Lithium Ion |
Battery Capacity |
9.0 Ah |
Tool Holder |
SDS-Max |
Max . Impact Energy |
15.7 J |
Impact Energy ( EPTA 05 / 2009 ) |
13.3 J |
No Load Speed |
177-355 rpm |
Blows Per Minute |
1,350-2,705 bpm |
Optimum Drilling Capacity [ Concrete ] |
24-42 mm |
Max . Drilling Capacity [ Concrete / Core bit ] |
48 / 125 mm |
Chipping Mode |
No |
Weight |
9.8 kg |
Length x Height |
597 x 284 mm |
Vibration Level |
9.0 m / s ² |
|
|
60V MAX * CORDLESS TOOLS |
|
Voltage |
60V |
Battery Chemistry |
Lithium Ion |
Battery Capacity |
9.0 Ah |
Tool Holder |
SDS-Max |
Max . Impact Energy |
7.3 J |
Impact Energy ( EPTA 05 / 2009 ) |
6.1 J |
No Load Speed |
540 rpm |
Blows Per Minute |
3150 bpm |
Optimum Drilling Capacity [ Concrete ] |
16-30 mm |
Max . Drilling Capacity [ Concrete / Core bit ] |
40 / 100 mm |
Chipping Mode |
Yes |
Weight |
6.65 kg |
Length x Height |
502 x 263 mm |
Vibration Level |
9.4 m / s ² |
|
|
|
Voltage |
60V |
Battery Chemistry |
Lithium Ion |
Chisel positions |
24 |
No Load Speed |
145 – 290 min-1 |
No-load beats per minute |
1105-2210 bpm |
Single impact energy ( EPTA 05 / 2009 |
19.4 J |
Optimum drilling range into concrete m |
28-52 mm |
Maximum drilling range in concrete |
52 mm |
Maximum core drilling range in concrete |
40-150 mm |
Weight |
9.5 kg |
|
|
