Rated Input
Power(Grill): 1100W
Rated Input
Power(Convection): 2500W
Oven Capacity: 28 L
Turntable Diameter: 315 mm
Outer Dimensions: 520 x 479 x 341 cm
Net Weight: Approx. 18.88 kg
Grounding Installation
DANGER
Electrical Shock Hazard
Touching some of the internal
components can cause serious
personal injury or death. Do not
disassemble this appliance.
WARNING
Electrical Shock Hazard
Improper use of the grounding
can result in electrical shock. Do
not plug into an outlet until the
appliance is properly installed
and earthed.
This appliance must be earthed.
In the event of an electrical short
circuit, this reduces the risk
of electrical shock through an
appropriate current-carrying wire
discharging any static charge.
This appliance is supplied with
a moulded three pin mains plug
for your safety and convenience.
en
The plug must be plugged
into an outlet that is properly
installed and earthed. Consult
a qualified electrician or service
technician if the instructions are
not completely understood or to
ensure the appliance has been
properly earthed. If required, use
a 3-wire extension cord, only.
1. A short power-supply cord is
provided to reduce the risks of
entanglement or trippingover
a longer cord.
2. If a long cord set or
extension cord is used:
1) The marked electrical
rating of the cord set
orextension cord should be at
least as great as the electrical
rating of the appliance.
2) The extension cord must
be a earthed type 3-wire
cord.
3) The long cord should
never drape over the
counter-top or tabletop
where it can be pulled on
by children or tripped over
unintentionally.
Installation
1. Select a level surface that
provide enough open space for the
intake and/or outlet opening vents.
