can be graphically displayed and the system controlled from a dedicated computer located within the centre .
The smoke extraction system and smoke zones for the building were designed by Elshove & Pryce . The air conditioning system was designed with consideration to the smoke zones . In the event of a fire , smoke is removed from the retail and mall areas via a combination of roof mounted smoke ventilators and smoke extract fan systems . Smoke paths and zones were carefully considered to ensure escape routes were maintained smoke free and routed away from the possible smoke / fire .
Assessment The nature of the South African Building Regulations ( Part T ) exposes the doctrine that any attempt to apply the Deemed-to-Satisfy-Rules to Extra-Ordinary Building Projects , ( In casu :
RATIONAL APPROACH - Neville Bramley Submittion of a Rational Approach for omitting a fixed automatic fire extinguishing system / s to roof and ceiling voids exceeding 800mm in depth , serving as a return air plenum and not being subdivided into 300m 2 fire compartments .
General Overview & Terms of Reference The application of Deemed-to-Satisfy-Rules in relation to complexes of the nature of Cape Gate .
• The application of Deemed-to-Satisfy-Rules in relation to achieving the statutory standard for Life Safety of Regulation T1 ( Supra ).
• The determination of degree of proof required to achieve the normative discretion mandated by Regulation T , viz . the conditions of the National Building Regulations & Building Standards Act , Act 103 of 1977 ( as amended , hereafter the Act ). It is assumed that reference to applicable terminology herein falls within the province of a competent reader .
CapeGate Regional Centre 121
