Slide-on hinges with one way spring for wooden doors
Slide-on- Ø35 mm opening 100 °- Serie 45
D
Arm crank 0
H = 17 + D – S
Arm crank 9
H = 8 + D – S
A
Ø 35
H
H
D
S
S
100 °
D
D = Drilling distance H = Plate height S = Overlay
Ø cup hole [ mm ] Opening
Cup drilling distance
[ mm ] Adjustment
Wood screws
Cup fixing
Knock-in
dowels
Euroscrews
Speed
Wood screws
Cup fixing
Knock-in
dowels
Euroscrews
Speed
35 100 ° 48 Screw W45V22AGG W45D22AGG W45P22AGG W45S22AGG W45V22BGG W45D22BGG W45P22BGG W45S22BGG
Drilling distances and cup fixing
6 Ø 35
Wood screw fixing Knock-in dowels fixing Premounted " Speed " fast fixing euroscrews fixing
48
10 10
V501 / G 4x16 Ø 10 Ø 5x10
Ø 10
Minimum reveal required
Opening 100 °
Cup drilling distance
D [ mm ]
3
4
5
Door thickness T [ mm ] Minimum reveal L [ mm ]
16 0.6 0.6 0.6
17 0.7 0.7 0.8
18 0.9 1.0 1.0
19 1.4 1.4 1.4
D
L
F
L
F
L
T
20 1.9 1.9 1.8
21 2.5 2.4 2.2
22 3.3 3.0 2.8
23 4.5 3.6 3.3
24 5.7 4.7 4.1
25 6.9 5.9 4.9
26 8.1 7.1 6.0
F = Gap
Please note that the gap“ F” should always be at least equal to minimum reveal required“ L”
For mounting plates see page 60 Ferrari 59
