Hinges

Slide-on hinges blind corner arm for wooden doors
Slide-on- Ø40 mm opening 95 °
Blind corner arm
D
A
H 1.5 3.0 4.5 6.0
30 min.
X
S
12.2
T
Ø 40 L
D
D = Drilling distance X = Plate fixing distance S = Overlay L = Minimum reveal H = Plate height
95 °
Base height H
1.5
3.0
4.5
6.0
D
X
S
4.0
30
6.0
4.5
3.0
1.5
5.0
28
6.0
4.5
3.0
1.5
6.0
26
6.0
4.5
3.0
1.5
7.0
24
6.0
4.5
3.0
1.5
8.0
22
6.0
4.5
3.0
1.5
Ø cup hole [ mm ]
Opening
Cup drilling distance
[ mm ] Adjustment
Cup fixing
Wood screws Knock-i n dowels Speed
40 95 ° 52 Screw C95074GMGZG C95076GMGZG C95102GMGZG
Drilling distances and cup fixing
B Ø 40
Wood screw fixing Knock-in dowels fixing " Speed " fast fixing
A
10 10
A [ mm ]
52
B [ mm ]
7.5
V501 / G 4x16
Ø 10 Ø 10
Minimum reveal required
Opening 95 °
Cup drilling distance
D [ mm ]
6
8
10
12
14
Door thickness T [ mm ] Minimum reveal L [ mm ]
24 1.1 1.1 1.0 1.0 1.0
25 1.2 1.2 1.2 1.2 1.1
26 1.5 1.4 1.4 1.3 1.3
D
L
F
T
27 1.7 1.6 1.6 1.5 1.5
28 1.9 1.8 1.8 1.7 1.7
29 2.1 2.0 2.0 1.9 1.9
30 2.4 2.3 2.2 2.1 2.1
31 2.6 2.5 2.5 2.4 2.3
32 2.9 2.8 2.7 2.7 2.6
F = Gap
Please note that the gap“ F” should always be at least equal to minimum reveal required“ L”
For mounting plates see page 60
58
