Hinges

Slide-on hinges for metal profiles inclined arm
Slide-on- opening 95 °
P
Inclined arm + 45 ° Inclined arm + 45 ° with overlay
X 45
X 45
H 1.5 3.0 4.5 6.0
0.5
L
T
S
H 1.5 3.0 4.5 6.0
0.5
L
T
S
Opening Adjustment Interax [ mm ]
95 ° Screw
95 °
D = Drilling distance X = Plate fixing distance S = Overlay L = Minimum reveal H = Plate height T = Door thickness
36
Plate height H
1.5
3.0
4.5
6.0
P
X
S
20
38
2.6
1.1
-0.4
-1.9
21
37
3.3
1.8
0.3
-1.2
22
36.5
4.0
2.5
1.0
-0.5
23
36
4.7
3.2
1.7
0.2
24
35
5.4
3.9
2.4
0.9
C95350EZGMG
Plate height H
1.5
3.0
4.5
6.0
P
X
S
20
39
8.2
6.7
5.2
3.7
21
38
9.0
7.5
6.0
4.5
22
37.5
9.7
8.2
6.7
5.2
23
37
10.4
8.9
7.4
5.9
24
36
11.0
9.5
8.0
6.5
C95350PZGMG
Slide-on hinges blind corner arm for metal profile
Slide-on- opening 95 °
P
Blind corner
H 1.5 3.0 4.5 6.0
30 min.
X
S
T
L
D = Drilling distance X = Plate fixing distance S = Overlay L = Minimum reveal H = Plate height T = Door thickness
95 °
Plate height H
1.5
3.0
4.5
6.0
P
X
S
20
37
5.5
4.0
2.5
1.0
21
36
5.5
4.0
2.5
1.0
22
35
5.5
4.0
2.5
1.0
23
34
5.5
4.0
2.5
1.0
24
33
5.5
4.0
2.5
1.0
Opening Adjustment Interax [ mm ]
95 ° Screw
36 C95350GZGMG
52 Ferrari
