Hinges
Hinges MINI clip for glass door
Anyway Clip Ø26 / 30 mm opening 95 °
Crank 3 H = 14 + D – S
Crank 9 H = 8 + D – S
S
Ø 26 / 30
H
D
H
D
S
95 °
Ø cup hole |
|
|
[ mm ] |
Opening |
Adjustment |
26 95 °
H = plate height D = drilling distance S = overlay
H = plate height D = drilling distance S = overlay
Screw C90315HNFZG * C90315BNFZG *
30 Screw C90370HNFZG * C90370BNFZG *
Hinge fixing
The hinge is mounted on the glass door connecting the ring to the cup with two screws. Once it is mounted connecting ring and screws are completely covered by the external face plate.
Screw code V220 / G
Face plate
H + 13.5
Hinge protrusion inside the cabinet
H + C-2
Ring T
8.5
H = plate height C = crank 3 / 9 / 17 T = min. 3.5 mm; max. = 6.0 mm
18 Ferrari
