Play
| 206
Dimensions
C
A
Model
A
B
F
870mm(34.25")
C
J
G
D
E
F
G
609mm(24.0")
B
J
SHR 11005R
51 2/
47 1/
20
8
24 1/
22
46 1/
36 1/
5
5
5
2
4
Dimensional information is in inches.
826mm(32.5") installer chooses.
1/2" (13mm)
* Electrical box can easily be relocated to the field to either the front or the back of the cabinet, depending on port direction
67mm(2.6")
mm(32.3")
E
620mm(24.4")
356mm(14.0")
559mm(22.0")
202mm(8.0")
D
Drain Spout
926mm(35.8")
Operation
920mm(36.3")
diagram
1181mm(46.5")
= fresh air to inside
= fresh air from outside
= stale air from inside
= stale air to outside
= recirculated air for defrost
Specifications
•
•
•
•
•
Model: SHR 11005R
Total assembled weight: 255 lbs
Cabinet: 20 ga. steel w/powder coat finish
Motors: backward curved blades
Mounting: unit may be suspended by using threaded rod (not supplied) or
•
•
•
placed on a platform
Insulated with 1” aluminum foil-face fiberglass insulation
to prevent condensation and meet the requirements of the UL 94HF
Filters: 6 washable electrostatic filters 11.75” x 15” x 0.26”
Core: 3 cores each 12” x 12” with a 15” depth
Accessories
Eco-TouchTM
Wall Control
page 199
EDF 1
Electronic Control
page 199
EDF 7
Electronic Dehumidistat
page 199
RTS 3
Electronic Timer
page 199
MDEH
Dehumidistat
page 199
MGE
Exhaust Grille
page 197
MGS
Supply Grille
page 196
IR
Iris Damper
page 200
