Play
| 202
Dimensions
C
F
B
A
J
G
Model
A
B
C
D
E
F
G
J
SHR 6905R
36 1/
2
32 5/
14
8
24 3/
22
46 1/
609mm(24.0")
870mm(34.25")
36 1/
16
8
2
4
Dimensional information is in inches.
1/2" (13mm)
* Electrical box can easily be relocated to the field to either the front or the back of the cabinet, depending 826mm(32.5") installer chooses.
on port direction
67mm(2.6")
mm(32.3")
E
620mm(24.4")
356mm(14.0")
559mm(22.0")
202mm(8.0")
D
Drain Spout
926mm(35.8")
920mm(36.3")
Operation diagram
1181mm(46.5")
= fresh air to inside
= fresh air from outside
= stale air from inside
= stale air to outside
= recirculated air for defrost
Specifications
•
•
•
•
•
Model: SHR 6905R
Total assembled weight: 200 lbs
Cabinet: 20 ga. steel w/powder coat finish
Motors: backward curved blades
Mounting: unit may be suspended by using threaded rod (not supplied) or
•
•
•
placed on a platform
Insulated with 1” aluminum foil-face fiberglass insulation
to prevent condensation and meet the requirements of the UL 94HF.
Core: 2 cores each 12” x 12” with a 15” depth
Filters: 4 washable electrostatic filters
Accessories
Eco-TouchTM
Wall Control
page 199
EDF 1
Electronic Control
page 199
EDF 7
Electronic Dehumidistat
page 199
RTS 3
Electronic Timer
page 199
MDEH
Dehumidistat
page 199
MGE
Exhaust Grille
page 197
MGS
Supply Grille
page 196
IR
Iris Damper
page 200
