102 2-2. Charging
quent DC charging to prevent a decline in the traction battery capacity.
lQuickly move from the DC charging space for other users after the DC charging is completed.
lIf DC charging is performed while
the traction battery is extremely cold, such as in cold weather,
steam may come out of the motor
compartment or dew may be formed on the hood. This is
because the heat, generated
while the traction battery is warmed, causes snow, ice, or
frost to evaporate. This is not a malfunction.
lThe charge amount is corrected
when the traction battery is fully charged, so 100 % remaining the
traction battery may not be displayed.
n How to set the DC charging power
You can change the DC charging power limit on the multimedia.
1 Select. 2 Select“ Vehicle customize”. 3 Select“ Charging”. 4 Select“ DC charging power”.
5 Select from“ Max”,“ 125kW”,“ 100kW”,“ 75kW”,“ 50kW”.
The maximum power when charging is limited to the selected power or
less. If“ Max” is selected, the vehicle will be charged with the maximum power that can be charged.
n Changing the“ Charging limit” settings
�P. 97
n If the DC charging power limit and“ Charging limit” settings cannot be changed
Remove the DC charging connector and immediately reinsert it while
the charging indicator is flashing in green. The settings will be changed to the default settings.
The settings will be return to the customized setting next time the charging is performed.
If the DC charging connector is locked immediately after inserting it,
press switch of the wireless
remote control or the door unlock switch on the driver’ s side 3 times at
intervals of about one second to stop DC charging, and then remove
the DC charging connector.
WARNING n Warnings for DC charging
Be sure to observe the following when using DC charging.
Failure to do so may cause an accident that could lead to death or serious injury.
lCheck that the DC charger and DC charging inlet are not damaged. If there is any damage to the DC charging inlet, do not perform a DC charge and have it inspected immediately at your SUBARU retailer.
lDo not touch the terminals of the DC charging connector or inlet with metallic sharp tips
( wires and needles), or allow a short circuit to occur with foreign objects.
lDo not insert anything other than the DC charging connector into the charging inlet.
lCheck that the DC charging cable is not coiled up or pinned underneath heavy objects.
lDo not connect conversion adapters, extension cords, etc., other than those provided by
SUBARU, between the DC charging connector and charging inlet.
