2-2. Charging
95 n Changing the“ Charging limit” settings
The upper limit of the charge capacity can be changed on the multimedia.
The selected upper limit value is common to AC charging and DC
charging.
1 Select. 2 Select“ Vehicle customize”. 3 Select“ Charging”. 4 Select“ Charging limit”.
5 Select“ Full”,“ 90 %”,“ 80 %”,“ 70 %”,“ 60 %” or“ 50 %”.
If the setting is changed during DC charging, charging may stop due to the operation of the DC charger timer and the traction battery cannot be fully charged.
n To initialize the setting of
charging current and charging limit temporarily
Remove the AC charging connector within 15 seconds after connect it, and then reconnect it immediately. The setting of charging current and charging limit will be temporarily initialized.
Also, if the procedure above is performed while the charging indicator is flashing normally and the charging schedule is registered,
“ Charge now” is turned on.( �P. 94)
WARNING n When charging Observe the following precautions.
Failure to do so may cause an unexpected accident, resulting in
death or serious injury.
lBefore charging, check that the charging inlet is not deformed, damaged or corroded, and
check that the inlet is free of foreign matter such as dirt, snow
and ice.
If there is dirt or dust in these areas, remove completely
before inserting the AC charging connector.
lDo not touch the terminals of the AC charging connector and charging inlet with a sharp metal objects( needles, etc.) or hands, or short them with foreign objects.
lIn order to stop charging at the charging station, follow the instructions of the AC charger.
lIf any heat, smoke, odors, noise or other abnormalities are noticed during charging, stop charging immediately.
lDo not charge the vehicle during a lightning storm.
lPrevent the AC charging cable from being caught in the door or back door.
lMake sure to connect the AC charging cable to an outlet within reach and do not use an extension cord.
2
Electric Vehicle system
