2-2. Charging
109
• Deleting registered items: Press“ Delete”.
A deletion confirmation message will be displayed.
Press“ Delete” to delete the selected charging schedule.
When a charging schedule is deleted, its icon is also deleted from the“ Charging schedule” screen.
n Turning“ Charge now” on 1 Display the“ Charging schedule” screen.( �P. 106)
2 Press“ Charge now”.
Each time the button is pressed,“ Charge now” switches between on and off.
After setting operations are complete, charging starts when the AC charging connector is connected.( �P. 92)
If“ Charge now” cannot be set to on even when performing the operations above, remove the AC charging connector while the charging indicator is flashing at the normal speed and then immediately reconnect it.
If this operation is performed, the setting of charging current and charging limit will be temporarily initialized.( �P. 95)
n Displaying next event Turn the power switch off.
Next event will be displayed according to the charging schedule
settings. *
*: If the multimedia customize content“ ACC customize” is not set to OFF, the ending screen will not be displayed. If it is this case, check the settings of the multimedia.
When press“ OK”, close Next charging event screen.
When press“ Charge now”, charge now is turned on.
nWhen all charging schedules are turned off
The icon is not displayed on the“ Charging schedule” screen.
The icon will be displayed by turning it ON on the“ Events” screen.
nWhen charging schedule setting operations are canceled
When the vehicle is in the following conditions, charging schedule setting operations are canceled.
lThe power switch is turned off before the settings are confirmed
lThe vehicle starts off
lA display with a higher priority than that of the charging schedule setting is shown
nWhen charging schedule are changed while charging
If the charging schedule is changed, Next Event will be updated and charging may stop. After changing
the charging schedule, please check Next Event.
2
Electric Vehicle system
