9-1. Specifications
661
* 2: Make sure to confirm that the brake system warning light( yellow) does
not illuminate.( If the brake system warning light illuminates, refer to P. 611)
Steering
Free play Less than 1.2 in.( 30 mm)
Tires and wheels
� 18-inch tires
Tire size 235 / 60R18 103V Front:
Tire inflation pressure
39 psi( 270 kPa, 2.7 kgf / cm 2 or bar)
( Recommended cold tire inflation pressure)
Rear: 39 psi( 270 kPa, 2.7 kgf / cm 2 or bar)
Wheel size
18 x 7 1 / 2J Wheel nut torque 76 ft • lbf( 103 N • m, 10.5 kgf • m)
� 20-inch tires
Tire size 235 / 50R20 100V Front:
Tire inflation pressure
38 psi( 260 kPa, 2.6 kgf / cm 2 or bar)
( Recommended cold tire inflation pressure)
Rear: 38 psi( 260 kPa, 2.6 kgf / cm 2 or bar)
Wheel size
20 x 7 1 / 2J Wheel nut torque 76 ft • lbf( 103 N • m, 10.5 kgf • m)
9
Vehicle specifications
