358 5-4. Using the driving support systems
When a pedestrian is detected
If a pedestrian is in the area behind the vehicle or if the rear camera detected that a pedestrian is approaching the vehicle from behind, the system urges caution from the driver by sounding the buzzer and displaying the detection of a pedestrian on the multimedia display as follows:
If a pedestrian is detected in area Buzzer: Sounds repeatedly Pedestrian detection icon: Blinks If a pedestrian is detected in area Buzzer( When the vehicle is stationary): Sounds 3 times Buzzer( When the vehicle is backing up, when a pedestrian approaches the rear of the vehicle): Sounds repeatedly Pedestrian detection icon: Blinks If the system determines that your vehicle may collide with a pedestrian in area Buzzer: Sounds repeatedly Pedestrian detection icon: Blinks
■ The rear camera detection function is operational when
●The power switch is in ON. ●RCD function is on. ●The shift position is in R.
● Advanced Park is not operating.
■ Setting the buzzer volume
The buzzer volume of the SUBARU Parking Assist, RCTA, and RCD can all be changed at once from the customize settings.( �P. 682)
■ Muting a buzzer temporarily
When an object is detected, the
temporary mute switch is displayed on the multimedia display. Select the switch to mute a buzzer of the
SUBARU Parking Assist, RCTA, and RCD all together.
Mute will be automatically canceled in the following situations:
●When the shift position is changed.
●When the vehicle speed exceeds a certain speed.
●When there is a malfunction in a sensor or the system is temporarily unavailable.
●When the operating function is disabled manually.
●When the power switch is turned off.
