Sensaphone IMS Sensors
IMS Room Humidity Sensor
Operating Temperature
Humidity
Sensor Series
Dimensions
32° to 122°F | -28° to 80°C
0 to 100%
IMS Solution
4.5 x 2.8 x 1.3” | 114 x 70 x 32mm
The IMS-4820 humidity sensor is designed to connect to the Sensaphone IMS series product line and monitor indoor humidity levels. The electrical
connection between the sensor and IMS unit is made via RJ-45 patch cable (not included). The sensor may be mounted either on a wall or to a
single-gang electrical box.
Part Name
Part Number
IMS Solution Room Humidity Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IMS-4820
IMS Room Humidity Sensor w/ Display
Operating Temperature
Humidity
Sensor Series
Dimensions
32° to 158°F | 0° to 70°C
5 to 95%
IMS Solution
4.8 x 2.9 x 1.9” | 120 x 73 x 47mm
The IMS-4821 humidity sensor is designed to connect to the Sensaphone IMS series product line and monitor indoor humidity. The electrical
connection between the sensor and IMS unit is made via RJ-45 patch cable (not included). The sensor may be mounted either on a wall or to a
single-gang electrical box. The IMS-4821 includes a LCD display for local readings.
Part Name
Part Number
IMS Solution Room Humidity Sensor w/ Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IMS-4821
IMS Water Detection Sensor
Sensor Temperature Range
Accuracy
Sensor Series
IMS Sensors & Accessories
Dimensions
32° to 140°F | 0° to 60°C
± .36°F | ±.2°C
Contact Series
6.3 x 3.3 x 2” | 158 x 83 x 50mm
The IMS-4830 Water Detection Sensor protects your server and equipment from damaging water leaks from malfunctioning HVAC systems, cafeteria
accidents, or any general plumbing failures in your facilities. The IMS-4830 is powered directly by the IMS unit.
Part Name
Part Number
IMS Solution Water Detection Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IMS-4830
Water Rope Extension for Zone Water Detection Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IMS-4831
