Sensaphone IMS-4000 Expansion
IMS Accessories
IMS-4000 Dual Relay Output Module
The IMS-4310 Dual Relay Output Module allows you to control two devices from any IMS-4000
Host or Node. Each output may be controlled either manually or automatically. Each output has
the option of providing either a dry relay contact or 12VDC power. Two switches located inside the
device select the output type.
Part Name
Part Number
IMS-4000 Dual Relay Output Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IMS-4310
IMS-4000 Dry Contact Node
Number of Inputs
Input Types
Internal Monitoring
Local Access
Operating Temperature
Physical
Power Consumption
Dry Contact, Normally Open or Normally Closed
AC Power, Backup Battery
Power LED, Ethernet LEDs
32°to 122°F | 0° to 50°C
Plug in power supply
Built in battery backup
IMS Monitoring Systems
Power Supply
8
7.3 x 5.5 x 1.5” | 185 x 140 x 381mm
2lbs | .9kg
2.5W
The IMS-4000 Dry Contact Node provides eight dry contact inputs (normally open/normally closed) and works in conjunction with the IMS Host. The
device communicates with the IMS-4000 Host via its Ethernet connection. The Dry Contact Node is a cost-effective solution when your application
only requires monitoring of dry contacts. With this device you do not need to use Dry Contact Bridges, thus reducing cost, installation time, and space.
This device includes four AA rechargeable NiMH batteries for power backup in the event of a power failure. Both main power and battery charge are
monitored and can be programmed to trip alarms as well. The unit comes in a black plastic enclosure with tabs for wall mounting. Rubber feet are also
included for placement on a shelf/desktop.
Part Name
Part Number
IMS-4000 Dry Contact Node . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IMS-4010
www.sensaphone.com
59
