GCW/HCW

Your Heating Specialist since 1949

CONTAINER
HEATERS

Gas Cylinder Warmers continued
Ordering Information:
Ordinary Locations and
Part Number Matrix

Class I Division I Groups B, C & D
GCW 15 43 150 1

1/2" (88mm)

Gas Cylinder Warmer Model
GCW- (for Ordinary Locations)
HCW- (CSA Class I Division I Groups B, C & D)
Diameter in inches

»3

Length in inches
Total Wattage
50, 100, 150
ONLY

1/2"
(13mm)
ON TOP

Voltage
1- (120VAC), 2- (240VAC)*
* GCW, 240VAC, 150W models have crimped wire ferrule terminated leads.

Hazardous-Area Rated Models (HCW series) Min / Max Sizes:
Diameter:

Minimum: 8” (203mm)

Maximum: 15” (381mm)
Length:

Minimum: 15” (381mm)

Maximum: 51” (1295mm)

2"
(51mm)

Ordinary Location Models (GCW series): can be designed for
a wide range of gas cylinder sizes. Call factory for details.

Accessories

Cylinder Base Insulation Pad- Placed between cylinder and
floor. Further insulates the cylinder from heatsinks such as a
concrete floor.
Valve Cover- Placed on top. Reduces the amount of heat loss
through the top of the cylinder.
Part Number

Description

GCWTOP

Gage/Valve Cover

GCW12B

12” (305mm) Cylinder Base Insulation Pad for 8” (203mm) Cylinder

GCW15B

15” (381mm) Cylinder Base Insulation Pad for 9”(229mm) Cylinder

GCW18B

18” (457mm) Cylinder Base Insulation Pad for 15” (381mm) Cylinder

Custom Sizes and Designs Available: Contact your local distributor or BriskHeat® for more information.
