CONTAINER
HEATERS

TOTE

Your Heating Specialist since 1949

TOTE Wrap-Around Tote Tank / IBC Heater continued
Specifications:

• Full coverage plug-and-play system
• Fits any tote tank from 40” x 40” (1016mm x
1016 mm) to 48” x 48” (1219mm x 1219mm)
• Three standard height sizes:
36” (914mm), 42” (1067mm), 48” (1220mm)
• Two separate heat zones (top and bottom)
• Adjustable thermostat: 50-160°F (10-71°C)
• Built-in manual reset high-limit safety thermostat set at 195°F (91°C) for each heat zone
• Attachment method: adjustable nylon straps
with buckles (Two across the top and three
around the tank)

• Silicone impregnated cloth outer and inner
material
• 1/4” (6mm) fiberglass insulation
• “Mouse hole” designed for spigot access
• Patented ground for your safety
• 120 / 240VAC, single-phase
• Total wattage:
120VAC = 1440 watts
240VAC = 2880 watts
• Power cord 6-foot (1.8M) long with 3-prong
power plug:
120VAC = NEMA 5-15
240VAC = NEMA 6-15
• Optional insulated top cover [reduces heat
loss and accelerates heat-up]

How to Measure Your Tote Tank / IBC:
1. Measure the height of the tote tank / IBC
(Not including the pallet or support stand).

Height

2. Measure the length and width of the tank.
This determines the tank perimeter for the
heated area.

x 2 +

h

W

x 2 =

Tank Length
Tank Width
Tank Perimeter
Note: If tank perimeter measurement is below 160”
(4064mm) or above 192” (4877mm), contact factory
for heater recommendation.

idt

Len
g

th

Ordering Information:
Height

Tank Perimeter
Minimum

Tank Perimeter
Maximum

Total Wattage
120V / 240V

Weight

Part Number
120VAC

Part Number
240VAC

36” (914 mm)

160” (4064 mm)

192” (4877 mm)

1440 / 2880

34 lbs (15 kg)

TOTE361-ADJ

TOTE362-ADJ

42” (1067 mm)

160” (4064 mm)

192” (4877 mm)

1440 / 2880

40 lbs (18 kg)

TOTE421-ADJ

TOTE422-ADJ

48” (1220 mm)

160” (4064 mm)

192” (4877 mm)

1440 / 2880

46 lbs (21 kg)

TOTE481-ADJ

TOTE482-ADJ

Celsius Label Option: Add a “-C” at the end of the part number.
European Lead Wire Option (240V Celsius Label Only): Add a “-CVE” at the end of the part number. Equipped with crimped
wire ferrule terminated leads.
RECOMMENDED: 240VAC model and top insulator is strongly recommended for applications that involve faster heat-up and
melting due to the higher wattage requirements.

Accessories:
Part Number
TOTE-TOP

Description
Insulated top cover, minimizes heat loss.

Custom Sizes and Designs Available: Contact your local distributor or BriskHeat® for more information.
