CONTAINER
HEATERS

FGDH

Your Heating Specialist since 1949

FGDH Full-Coverage Drum Heaters

• Easily control temperatures with the
programmable digital controller.
• Display is mounted on top of controller box
for increased visibility and user convenience.
• Displays in °F (°C is available upon request)
Single-Zone Model

Dual-Zone Model

Ordering Information:

For Celsius Control Optio n: Add a “C” at the end of the part number.

For Metal Drums - Single Zone (FGDH Series)
Size
Gallon (Liter)

Diameter
in (mm)

Height
in (mm)

Number
of Zones

Total
Wattage

Part Number
120VAC

Part Number
240VAC

55 (208)

22.3 (566)

36.4 (924)

1

1600

FGDHC55120D

FGDHC55240D*

30 (114)

18.6 (473)

29.5 (749)

1

1160

FGDHC30120D

FGDHC30240D

16 (61)

14.0 (355)

26.7 (678)

1

870

FGDHC15120D

FGDHC15240D

5 (19)

11.1 (282)

13.5 (343)

1

550

FGDHC5120D

FGDHC5240D

* 240VAC Celsius models have crimped wire ferrule terminated leads.

For Metal Drums - Dual Zone (FGDDC Series)
Designed to quickly melt viscous materials like molasses, syrups, etc.
Size
Gallon (Liter)

Diameter
in (mm)

Height
in (mm)

Number
of Zones

Total
Wattage

Part Number
240VAC

55 (208)

22.3 (566)

36.4 (924)

2

3200
(1600 per zone)

FGDDC55240D*

* 240VAC Celsius models have crimped wire ferrule terminated leads.

For Poly Drums - Single Zone (FGPDH Series)
Size
Gallon (Liter)

Diameter
in (mm)

Height
in (mm)

Number
of Zones

Total
Wattage

Part Number
120VAC

Part Number
240VAC

55 (208)

22.3 (566)

36.4 (924)

1

770

FGPDHC55120D

FGPDHC55240D*

* 240VAC Celsius models have crimped wire ferrule terminated leads.

If your drum diameter is greater than what is shown, an FGDHSTRIP expansion strip may be required.

Accessories:
Part
Number

Description

FGDC55

Drum Insulation Cover for 55 gallon

FGDHSTRIP

6” (152mm) wide strip that expands heater to fit up to a
24.2” (615mm) diameter drum. Strip is necessary for heater to fit
around drums with removable lids.

Drum Covers Help Reduce Heat Loss
and Speed up Heat-up Time

Custom Sizes and Designs Available: Contact your local distributor or BriskHeat® for more information.
