GBH

Your Heating Specialist since 1949

Silicone Rubber Griffin Beaker Heaters
Product Highlights
Provides Even Heat for Griffin and
Standard Beaker Heating Applications.
Removable with hook and loop
fastener. Easy-Access to Graduation.
Moisture and Chemical Resistant.
No Need to Worry About Spills.
Specifications:
•
•
•
•
•
•
•
•

•

Maximum exposure temperature: 232°C (450°F)
120 or 240VAC
Power density: 5.0 watts/in2 (0.008 watts/mm2)
Heating element is laminated between two layers of
15mil fiberglass reinforced silicone rubber
1” (25mm) wide hook and loop fastener
Moisture, chemical, and radiation resistant
Dielectric strength of over 2000 volts
24” (610mm) long power leads with

- 120VAC: Standard 2-prong NEMA 1-15 plug

- 240VAC: Crimped wire ferrule terminated leads

Size
ml

Diameter
in (mm)

Heater Height
in (mm)

Heater Width
In (mm)

Total
Watts

Part Number
120VAC

Part Number
240VAC

250

2.7 (69)

3.0 (76)

12.25 (311)

150

GBH0250-1

GBH0250-2

400

3.0 (76)

3.5 (89)

13.75 (349)

200

GBH0400-1

GBH0400-2

600

3.6 (91)

4.0 (102)

15.00 (381)

250

GBH0600-1

GBH0600-2

1000

4.3 (109)

4.6 (117)

17.25 (438)

350

GBH1000-1

GBH1000-2

LABORATORY

Ordering Information:

IMPORTANT: Temperature controller is required for this product. See pages 86 through 104 for options.
BriskHeat® offers a wide variety of temperature control options
including the SDC Benchtop Digital Temperature Controller.

Need a different size or have a different object to heat? We can design a heater
specifically for your application. Contact us or your local distributor for more details.
