HM

Your Heating Specialist since 1949

HM Table Top Heating Mantles
Product Highlights

Temperatures up to

Self-supporting: can be placed directly
on counter top
Easy viewing of flask contents

900°F (482°C)

Stackable for easy storage
Includes 6-foot (1.8m) power cord with
either a NEMA 1-15 (for 120VAC) or
NEMA 6-15 (for 240VAC) plug

Ordering Information:
Size
ml
50
100
250
500
1000
2000
3000
5000

Total
Watts
52
70
143
210
377
520
550
620

Part Number
120VAC
240VAC
HM0050VF1
HM0050VF2
HM0100VF1
HM0100VF2
HM0250VF1
HM0250VF2
HM0500VF1
HM0500VF2
HM1000VF1
HM1000VF2
H M2000VF1
HM2000VF2
HM3000VF1
HM3000VF2
HM5000VF1
HM5000VF2

LABORATORY

IMPORTANT: Temperature controller is required for this product. See pages 86 through 104 for options.

Temperature Controllers for Heating Mantles
SDC Benchtop Temperature Controller
Features:
• Temperature control range: 32-999°F (°F models) or
0-700°C (°C models)
• Includes J-type or K-type thermocouple sensor
- 5-foot (1.5 m) factory installed
• 120 VAC or 240 VAC power input
• 10-Amp Fused Output
• Small Unit Size
TS0 Portable Bulb and Capillary Temperature Controller
Features:
• 120 or 240VAC
• 15 amps
• 4-foot copper bulb and capillary
• Compact portable design
• Plug-in operation

TP0 Portable Time Percentage Dial Temperature Controller
Features:
• 120 or 240VAC
• 15 amps
• Compact portable design
• Plug-in operation
The TP0 series controller varies the proportion (length)
of time a heater is in the “on” or “off” heating mode.
The heating application will determine the actual
percentage set point required. The controller does not
use a temperature sensor and therefore satisfactory
operation requires occasional supervision under
changing load conditions.
X2-series PID Temperature Controller
Features:
• 120VAC or 240VAC
• Programmable to either °C or °F
• Type J or K thermocouple input
• Compact, plug-and-play design
• Advanced PID control
• Simple three key user control

For more information and choices, see pages 86 through 104 for the full temperature controller section.
