BS0

Your Heating Specialist since 1949

XtremeFLEX® BS0 Silicone Rubber Heating Tapes
Product Highlights
Moisture and chemical resistant
Exceptional flexibility
Rapid thermal response
Exceptional durability
Suitable for electrically conductive surfaces
Choice of power leads on same end or opposite ends

Specifications:

Maximum exposure temperature: 450°F (232°C)
Silicone rubber extruded outer sheath
Fiberglass knitted and braided construction
Moisture and chemical resistant
Power density: 4.3 W/in2 (0.007 W/mm2)
120 or 240VAC
Electrical leads on same end
Ingress Protection Rating: IP54

HEATING TAPE

•
•
•
•
•
•
•
•

Ordering Information:
Width
in (mm)
0.5 (13)
0.5 (13)
0.5 (13)
0.5 (13)
0.5 (13)
0.5 (13)
1.0 (25)
1.0 (25)
1.0 (25)
1.0 (25)
1.0 (25)
1.0 (25)
1.0 (25)
1.0 (25)
1.0 (25)
1.0 (25)
2.0 (51)
2.0 (51)
2.0 (51)
2.0 (51)
2.0 (51)
2.0 (51)
2.0 (51)
2.0 (51)
2.0 (51)
2.0 (51)

Length
ft (m)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)
12 (3.7)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)
12 (3.7)
14 (4.3)
16 (4.9)
18 (5.5)
20 (6.1)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)
12 (3.7)
14 (4.3)
16 (4.9)
18 (5.5)
20 (6.1)

Total
Watts
52
104
156
209
261
313
104
209
313
418
522
627
731
836
940
1075/1045
209
418
627
836
1045
1254
1463
1627
1881
2090

Part No.
120VAC
BS0051020L
BS0051040L
BS0051060L
BS0051080L
BS0051100L
BS0051120L
BS0101020L
BS0101040L
BS0101060L
BS0101080L
BS0101100L
BS0101120L
BS0101140L
BS0101160L
BS0101180L
BS0101200L
BS0201020L
BS0201040L
BS0201060L
BS0201080L
BS0201100L
BS0201120L
BS0201140L
BS0201160L
BS0201180L*
BS0201200L*

Part No.
240VAC
BS0052020L**
BS0052040L**
BS0052060L**
BS0052080L**
BS0052100L**
BS0052120L**
BS0102020L**
BS0102040L**
BS0102060L**
BS0102080L**
BS0102100L**
BS0102120L**
BS0102140L**
BS0102160L**
BS0102180L**
BS0102200L**
BS0202020L*
BS0202040L*
BS0202060L*
BS0202080L*
BS0202100L*
BS0202120L*
BS0202140L*
BS0202160L*
BS0202180L*
BS0202200L*

Adhesive Tape

Provides intimate contact with surface to be heated.
A heating tape essential!
Part
Number
PSAT36A
AAT260
AAT2180

Material
Fiberglass
Aluminum
Aluminum

Width
in (mm)
0.5 (13)
2.0 (51)
2.0 (51)

Length
Yards (m)
36 (32.9)
60 (54.8)
60 (54.8)

Temperature
Limit
350°F (176°C)
350°F (176°C)
550°F (288°C)

Ordering option: For a single power lead on opposite ends,
remove “L” from end of part number.
* Plug not included

** Ferrule crimp wire termination

IMPORTANT: Temperature controller is required for this product. See pages 86 through 104 for options.
