14th-Edition-BriskHeat-Product-Catalog A | Page 44

B00/BW0

Your Heating Specialist since 1949

XtremeFLEX® B00 and BW0 Standard Insulated Heating Tapes
Product Highlights
Excellent flexibility
Rapid thermal response
Exceptional durability
Suitable for non-conductive electrical surfaces
only (i.e. glass)
Choice of power leads on same end or opposite
ends

HEATING TAPE

Includes high-temperature tie-downs for easy
installatio n

Specifications:
•

•

•

•
•

Maximum exposure temperature:

B00 series: 900°F (482°C)

BW0 series:1400°F (760°C)
Construction:

B00 series: fiberglass knitted and braided

BW0 series: Samox® knitted and braided
Power density:

B00 series: 8.6 watts/in2 (0.013 watts/mm2)

BW0 series: 13.1 watts/in2 (0.020 watts/mm2)
120 or 240VAC
Ingress Protection Rating: IP5X

Ordering Information:

B00 series: Standard Insulated Heating Tape
Power Leads on Same End
Width
in (mm)
0.5 (13)
0.5 (13)
0.5 (13)
0.5 (13)
0.5 (13)
1.0 (25)
1.0 (25)
1.0 (25)
1.0 (25)
1.0 (25)

Length
ft (m)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)

Total
Watts
105/100
210
310
420
520
210
420
620
830
1045

Part No.
120VAC
B00051020L
B00051040L
B00051060L
B00051080L
B00051100L
B00101020L
B00101040L
B00101060L
B00101080L
N/A

Part No.
240VAC
B00052020L*
B00052040L*
B00052060L*
B00052080L*
B00052100L*
B00102020L*
B00102040L*
B00102060L*
B00102080L*
B00102100L*

* Plug not included

BW0 series: High Temperature Standard Insulated Heating Tape
Power Leads on Same End
Width
in (mm)
0.5 (13)
0.5 (13)
0.5 (13)
0.5 (13)
0.5 (13)
0.5 (13)
1.0 (25)
1.0 (25)
1.0 (25)
1.0 (25)

Length
ft (m)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)
12 (3.7)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)

Total
Watts
160
310
470
620
780
940
310
620
940
1250

Part No.
120VAC
BW0051020L
BW0051040L
BW0051060L
BW0051080L
N/A
N/A
BW0101020L
BW0101040L
N/A
N/A

Part No.
240VAC
BW0052020L*
BW0052040L*
BW0052060L*
BW0052080L*
BW0052100L*
BW0052120L*
BW0102020L*
BW0102040L*
BW0102060L*
BW0102080L*

* Plug not included

Ordering option: For a single power lead on opposite ends, remove “L” from end of part number

IMPORTANT: Temperature controller is required for this product. See pages 86 through 104 for options.
