BIH/BWH

Your Heating Specialist since 1949

XtremeFLEX® BIH and BWH Heavy Insulated Heating Tapes
Product Highlights
Exceptional flexibility and durability
Rapid thermal response
Suitable for electrically conductive surfaces
Choice of power leads on same end or opposite ends
Includes high-temperature tie-downs for easy installation

Specifications:

Maximum exposure temperature:
BIH series: 900°F (482°C)
BWH series:1400°F (760°C)
Construction:
BIH series: fiberglass knitted and braided
BWH series: Samox® knitted and braided
Power density:
BIH series: Standard: 8.6 W/in2 (0.013 W/mm2
Wide†:
5.1 W/in2 (0.008 W/mm2)

BWH series: Standard: 13.1 W/in2 (0.020 W/mm2)
Wide†:
7.7 W/in2 (0.012 W/mm2)
• Ingress Protection Rating: IP5X

HEATING TAPE

•

•

•

† 1.75” (44mm) wide tape or greater

Ordering Information:

BIH series: Heavy Insulated

BWH series: High Temperature Heavy Insulated

Power Leads on Same End
Width
in (mm)
0.50 (13)
0.50 (13)
0.50 (13)
0.50 (13)
0.50 (13)
0.50 (13)
1.00 (25)
1.00 (25)
1.00 (25)
1.00 (25)
1.00 (25)
1.00 (25)
1.75 (44)
1.75 (44)
1.75 (44)
1.75 (44)
1.75 (44)
2.50 (64)
2.50 (64)
2.50 (64)
2.50 (64)
2.50 (64)
3.25 (83)
3.25 (83)
3.25 (83)
3.25 (83)
3.25 (83)

Length
ft (m)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)
12 (3.7)
1 (0.3)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)

Total
Watts
105
210
310
420
520
620
105
210
420
620
830
1045
209
418
627
836
1045/1040
313
627
940
1254
1567
418
836
1254
1672
2090

Power Leads on Same End

Part No.
120VAC
BIH051020L
BIH051040L
BIH051060L
BIH051080L
BIH051100L
BIH051120L
BIH101010L
BIH101020L
BIH101040L
BIH101060L
BIH101080L
BIH101100L
BIH171020L
BIH171040L
BIH171060L
BIH171080L
BIH171100L
BIH251020L
BIH251040L
BIH251060L
BIH251080L
BIH251100L
BIH321020L
BIH321040L
BIH321060L
BIH321080L*
BIH321100L*

Part No.
240VAC
BIH052020L**
BIH052040L**
BIH052060L**
BIH052080L**
BIH052100L**
BIH052120L**
N/A
BIH102020L**
BIH102040L**
BIH102060L**
BIH102080L**
BIH102100L**
BIH172020L*
BIH172040L*
BIH172060L*
BIH172080L*
BIH172100L*
BIH252020L*
BIH252040L*
BIH252060L*
BIH252080L*
BIH252100L*
BIH322020L*
BIH322040L*
BIH322060L*
BIH322080L*
BIH322100L*

Width
in (mm)
0.50 (13)
0.50 (13)
0.50 (13)
0.50 (13)
0.50 (13)
0.50 (13)
1.00 (25)
1.00 (25)
1.00 (25)
1.00 (25)
1.00 (25)
1.75 (44)
1.75 (44)
1.75 (44)
1.75 (44)
1.75 (44)
2.50 (64)
2.50 (64)
2.50 (64)
2.50 (64)
2.50 (64)
3.25 (83)
3.25 (83)
3.25 (83)
3.25 (83)
3.25 (83)

Length
ft (m)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)
12 (3.7)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)

Total
Watts
156
313
470
627
783
940
313
627
940
1254/1245
1570/1567
313
627
940
1254
1570
470
940
1411
1881
2351
627
1254
1881
2508
3135

Part No.
120VAC
BWH051020L
BWH051040L
BWH051060L
BWH051080L
N/A
N/A
BWH101020L
BWH101040L
BWH101060L
BWH101080L
N/A
BWH171020L
BWH171040L
BWH171060L
BWH171080L
BWH171100L
BWH251020L
BWH251040L
BWH251060L
BWH251080L*
N/A
BWH321020L
BWH321040L
BWH321060L*
BWH321080L*
BWH321100L*

Part No.
240VAC
BWH052020L**
BWH052040L**
BWH052060L**
BWH052080L**
BWH052100L**
BWH052120L**
BWH102020L**
BWH102040L**
BWH102060L**
BWH102080L**
BWH102100L**
BWH172020L*
BWH172040L*
BWH172060L*
BWH172080L*
BWH172100L*
BWH252020L*
BWH252040L*
BWH252060L*
BWH252080L*
BWH252100L*
BWH322020L*
BWH322040L*
BWH322060L*
BWH322080L*
BWH322100L*

* Bare wire power leads, plug not included
** Ferrule crimp wire termination
Ordering option: For a single power lead on opposite ends, remove “L” from end of part number

IMPORTANT: Temperature controller is required for this product. See pages 86 through 104 for options.
